uPC3 – rel 1.8 – 11/2021
13
PreHeater
Control
• PID controller – Heating
• Addtitonal temp. sensor
uPC3
I/O
Descrition
Type
Note
AO2
Heating control signal
0-10V
DC
For CBX
B6
Temp. after heater
NTC
AO4
Heating control signal
0-10V
DC
For
compact
B2
Temp. after heater
NTC
NO3
Main heating – Start signal
+24V DC
B5
Back water temperature
NTC
DI2
Heater alarm
NC
ReHeater
Control
• PID controller – Heating
• Addtitonal temp. sensor
uPC3
I/O
Descrition
Type
Note
Y1*
Heating control signal
0-10V
DC
NO1*
Main heating – Start signal
+24V DC
AO2**
Heating control signal
0-10V
DC
NO3**
Main heating – Start signal
+24V DC
DI2
Heater alarm
NC
* For systems when the heater behind the DXH exchanger.
** For systems when the heater after the main heater.
