VTS Ventus VVS300 [16/47] Additional settings for the control circuit module on the screens
![VTS American VENTUS AVS 230 [16/47] Additional settings for the control circuit module on the screens](/views2/1894674/page16/bg10.png)
uPC3 – rel 1.8 – 11/2021
16
I.R. – Input register
H.R – Holding register
Command type
Data type
Addr.
InputRegister
INT
0
InputRegister
INT
1
InputRegister
INT
2
InputRegister
INT
3
HoldingRegister
INT
0
HoldingRegister
INT
1
HoldingRegister
INT
2
HoldingRegister
INT
3
Pressure sensor
uPC3 (new)
uPC (old)
I.R.0
SPS
I.R.1
H.R.0
DPT
DPC
VTS
H.R.1
Important information when using an external
pressure transducer, turn off the measurement on the
Control-Circuit board.
HMI Advanced ► Menu ► Other ► J03/J04
Humidity sensor
uPC3 (new)
uPC (old)
I.R.0
I.R.1
DXH
I.R.2
H.R.0
HCRH
VTS
H.R.1
H.R.2
RH
Important information when using an external humidity
transducer, turn off the measurement on the Control-
Circuit board.
HMI Advanced ► Menu ► Other ► J03/J04
CO2 sensor
uPC3 (new)
uPC (old)
I.R.0
I.R.1
I.R.2
H.R.0
HTC
VTS
H.R.1
CDD
H.R.2
I.R.3
DSC
H.R.3
Module I/O
HMI Advanced ► Menu ► Other ► J03
The menu from which we activate individual extension
modules.
VTS – MainBoard – Control Circuit
Additional settings for the Control-Circuit module on
the screens:
