1. INTRODUCTION
1.1 Main features
Usability and display – The menu-based system allows the application to be configured as a tool for instant
diagnostics. All this is possible by the immediately accessible overview screens.
Quick menus - information on the status is accessible directly from the main menu, without needing to access the
submenus. Configuration, active function and operating temperature information are arranged in loops of screens,
scrolled by pressing the DOWN button from the main screen.
List of functions:
Main features
Application code will determine the unit type
Heat recovery
AD – Supply-exhaust application without recovery
AG – Supply-exhaust application with glycol heat recovery
AP – Supply-exhaust application with plate cross-flow recuperator
AR – Supply-exhaust application with rotary regenerator
AS – Supply application
Coils management
HW – Water heater
HE – Electric heater
CW – Water cooler
DX – Direct expansion
CWHW - Cooler heater coil
EVPR.HMFR – Evaporative humidifier
Fans
Up to 10 supply fans
Up to 10 exhaust fans
Option of redundant function with 2 fans
Hardware
uPC3 extra small
User interface
HMI Advanced
Languages
EN
Unit of measure
International
USA
Alarms
Automatic and manual management
Log from application
Supervisor protocol
Modbus
Bacnet
