uPC3 – rel 1.8 – 11/2021
28
level or air flow setpoint (if differential pressure
probe is present).
Besides the daily time band, it will be possible to
set up to 3 special periods and 6 special days, for
each one it will be possible to set the unit status
(Off, Economy, Pre-comfort, Comfort, Auto).
The time bands of the uPC3 and the set of the HMI
Basic have the same priority. The last set that
comes it will wins.
The options of the scheduler are:
1. No scheduler
2. Scheduler by uPC3
3. Scheduler by HMI Basic
4. Scheduler by uPC3, activation by HMI
Basic
