uPC3 – rel 1.8 – 11/2021
9
DI5
Return filter
Enabled for unit without humidity / DI
win/sum / MainBoard activity / PCB-EC
activity
DI6
Remote Off or change Mode
On the screen G08 in Menu – In/Out settings
you can change the operating mode.
Exp. 13 – PCB EC
Supply filter
MB - IN1
Enabled with PCB EC
Exp. 13 – PCB EC
Exhaust filter
MB - IN2
Enabled with PCB EC
Digital outputs
Descrition
Type
Note
NO1
Main heating (heater or pump)
Enabled in case of heating device
NO1
Re-Heater
Enabled in unit with DX_H and second
heater
NO2
Supply and exhaust damper
Always enabled
NO3
Global Alarm
Enabled for unit without reheater or
preheater
NO3
ReHeater
Enabled in case of reheater device
NO3
PreHeater
Enabled in case of preheater device
NO4
Main cooling 1 (DX or pump)
Enabled in case of cooling device
NO4
DX_H start
Enabled in case of DX_H device
NO5
Main cooling 2
Enabled in case of cooling 2 step device
NO5
DXH Reverse
Enabled in caes of cooling/heating coil
NO5
Humidity
Enabled in case of humidity device
NO5
Glicol pump
Enabled in case of recovery glicol device
NO5
Redundant
Enabled in case of redundant device
NO6
Heating 2nd stage
Enabled in case of 2
nd
heating device for HE
unit
NO6
Humidifier
Enabled in case of humidifier device
NO6
DX_H 2nd stage
Enabled in case of 2
nd
DX_H
Analog outputs
Descrition
Type
Note
Y1
Heating output
0-10V
Enabled in case of heating device
Y1
Re-heating output
0-10V
Enabled in case of Re-Heater device
Y3
Cooling output
0-10V
Enabled in case of cooling device
Y3
Mixing damper output
0-10V
Enabled in case of Mixing damper device
Y3
Recovery output
0-10V
Enabled in case of Recovery device
Exp. 13 – PCB EC
Heat recovery
MB-AO1
Enabled in case of heat recovery
Exp. 13 – PCB EC
Mixing chamber signal
MB-AO2
Enabled in case of mixing chamber
Exp. 18 - MainBoard
Heat recovery
MB-AO1
Enabled in case of heat recovery
Exp. 18 - MainBoard
Mixing chamber signal
MB-AO2
Enabled in case of mixing chamber
Exp. 18 - MainBoard
Humidifier
MB-AO3
Enabled in case of humidifier
Exp. 18 - MainBoard
Preheater output
MB-AO4
Enabled in case of preheater
Attention: Structure of the software in class A: the thermal protection safeties for overload and high pressure
must act directly on the compressor actuator and are thus wired in series with the command for coil of the compressor
contactor.
