Vitek VT-1636 ST [4/40] English

purpose of repair, please, apply to a certified

service center.

• Store the device in dry, cool, inaccessible for

children place.

• The device is designed only for household

use, any commercial use of the juice extractor

is not allowed.

Before you start

• Remove the device out of the package.

• Before switching the device for the first time,

make sure that working voltage of the device

corresponds to electrical mains voltage.

• Thoroughly clean all detachable parts,

which will be in contact with products, and

dry them.

Note: Be careful when holding the filtergrater,

the grater has a sharp surface.

• Wash vegetables/fruit, cut them into pieces,

which can easily come through the juice

extractor cover neck.

• During squeezing of juice from “stone” fruit

(e.g. cherry, peach etc.), remove stones from

fruit.

Making juice

• Put the juice extractor on flat dry and stable

surface.

• Before assembling make sure that the device

is switched off and disconnected from

electrical mains.

• Install the juice collector (5) on the motor

module (8).

• Install the filtergrater (4) in the juice collector

(5).

Note: in case of finding of mechanical damages

stop using the filtergrater.

• Install the cover (3) on the juice collector and

fasten it with the help of the clamp (7).

• Install the pulp container(10).

• Connect the mains cable plug to socket.

• Switch on the juice extractor by setting the

switch (9) to position “1” (low speed) or

position “2” (high speed).

Note:

 “low speed” – for squeezing of juice from soft

vegetables/fruit (tomatoes, pears, strawber-

ries, oranges, plums, grapes, pumpkin, on-

ion, cucumbers etc.).

 “high speed” – for squeezing of juice from

hard vegetables/fruit (artichokes, carrot,

apples, pepper, beet, potatoes, pineapples,

marrow, celery, spinach, dill, leek etc.).

Attention! During treatment of products caus-

ing additional load to the motor (viscous and/or

hard products), to avoid motor stoppage in the

process of operation and its further failure, it is

recommended to use high speed for squeezing

of juice (position “2”).

• The juice extractor will switch on only if all

detachable parts are correctly installed, and

the cover (3) is fastened with the clamp(7).

• Start loading products only with motor

running.

• Gradually lower precut pieces of vegetables

and fruit into the cover neck (2) and slightly

push them with the pusher (1). Do not apply

to much load to the pusher, as this can impair

quality of the resulted juice and even stop

rotation of the filtergrater (4). The more

slowly vegetables and fruit are treated, the

more juice you will get.

• It is not allowed to put fingers and other

objects into the cover neck (2).

• During operation, periodically check

condition of the filtergrater (4) against

clogging of the filter mesh with pulp, and if

necessary, clean the filtergrater (4).

• If the filter mesh is clogged with squeezed

product, to avoid a failure of the device,

switch it off and clean the filtergrater (4).

• Watch over filling up of the pulp container

(10). If the container is filled up, switch

the juice extractor off, take the cable plug

out of socket, and remove pulp from the

container.

ATTENTION: The maximal allowable con-

tinuous operation time should not exceed

2 minutes with subsequent break of at least

3 minutes.

During the operation clean the lid and the grating

filter from the pulp periodically. Maximal allowed

amount of vegetables/fruit is 2 kg. After that

switch the unit off and clean the lid and the

grating filter from the pulp.

ENGLISH
