ŒiliSæÎÎÉgiæœSiaÎSES WS 24 180 WS 24 230 WS 24 230 GVX WS 24 130 E WS 24 230 E WS 24 230 EGVX Kickback and Related Warnings Kickback is a sudden reaction to a pinched or snagged rotating wheel backing pad brush or any other accessory Pinching or snagging causes rapid stalling of the rotating accessory which in turn causes the uncontrolled power tool to be forced in the direction opposite of the accessory s rotation at the point of the binding Rated input 2400 W 2400 W 2400 W Output 1560 W 1560 W 1560 W Max no load speed 8500 min 1 6600 min 1 6600 min 1 Grinding disk diameter 180 mm 230 mm 230 mm Thread of work spindle M 14 M 14 M 14 Weight without cable 5 0 kg 5 1 kg 5 3 kg For example if an abrasive wheel is snagged or pinched by the workpiece the edge of the wheel that is entering into the pinch point can dig into the surface of the material causing the wheel to climb out or kick out The wheel may either jump toward or away from the operator depending on direction of the wheel s movement at the point of pinching Abrasive wheels may also break under these conditions Noise Vibration Information Measured values determined according to EN 6O745 Typically the A weighted noise levels of the tool are Sound pressure level K 3dB A 94 dB A 93 dB A 93 dB A Sound power level K 3dB A 105 dB A 104 dB A 104 dB A Wear ear protection Kickback is the result of power tool misuse and or incorrect operating procedures or conditions and can be avoided by taking proper precautions as given below Total vibration values vector sum in the three axes determined according to EN 60745 Surface grinding vibration emission value a 6 m s2 6 m s2 5 2 m s2 Uncertainty K 1 5 m s2 1 5 m s2 1 5 m s2 Disk sanding vibration emission value a 2 5 m s2 2 5 m s2 2 5 m s2 Uncertainty K 1 5 m s2 1 5 m s2 1 5 m s2 For other applications e g Abrasive Cutting Off Operations or Wire Brushing other vibration values could occure a Maintain a firm grip on the power tool and position your body and arm to allow you to resist kickback forces Always use auxiliary handle if provided for maximum control over kickback or torque reaction during start up The operator can control torque reactions or kickback forces if proper precautions are taken b Never place your hand near the rotating accessory Accessory may kickback over your hand WARNING The vibration emission level given in this information sheet has been measured in accordance with a standardised test given in EN 60745 and may be used to compare one tool with another It may be used for a preliminary assessment of exposure c Do not position your body in the area where power tool will move if kickback occurs Kickback will propel the tool in direction opposite to the wheel s movement at the point of snagging The declared vibration emission level represents the main applications of the tool However if the tool is used for different applications with different accessories or pooriy maintained the vibration emission may differ This may significantly increase the exposure level over the total working period d Use special care when working corners sharp edges etc Avoid bouncing and snagging the accessory Corners sharp edges or bouncing have a tendency to snag the rotating accessory and cause loss of control or kickback An estimation of the level of exposure to vibration should also take into account the times when the tool is switched off or when it is running but not actually doing the job This may significantly reduce the exposure level over the total working period Identify additional safety measures to protect the operator from the effects of vibration such as maintain the tool and the accessories keep the hands warm organisation of work patterns ZB WARNING Read all safety warnings and all instructions including those given in the accompanying brochure Failure to follow the warnings and instructions may result in electric shock fire and or serious injury Save all warnings and instructions for future reference SAFETY INSTRUCTIONS Safety Warnings Common for Grinding Sanding Wire Brushing or Abrasive Cutting Off Operations a This power tool is intended to function as a grinder sander wire brush or cut off tool Read all safety warnings instructions illustrationsand specifications provided with this power tool Failure to follow all instructions listed below may result in electric shock fire and or serious injury b Operations as polishing are not recommended to be performed with this power tool Operations for which the power tool was not designed may create a hazard and cause personal injury undamaged accessory After inspecting and installing an accessory position yourself and bystanders away from the plane of the rotating accessory and run the power tool at maximum no load speed for one minute Damaged accessories will normally break apart during this test time d The rated speed of the accessory must be at least equal to the maximum speed marked on the power tool Accessories running faster than their rated speed can break and fly apart k Position the cord clear of the spinning accessory If you lose control the cord may be cut or snagged and your hand or arm may be pulled into the spinning accessory g Do not use a damaged accessory Before each use inspect the accessory such as abrasive wheels for chips and cracks backing pad for cracks tear or excess wear wire brush for loose or cracked wires If power tool or accessory is dropped inspect for damage or install an 20 ENGLISH a Use only wheel types that are recommended for your power tool and the specific guard designed for the selected wheel Wheels for which the power tool was not designed cannot be adequately guarded and are unsafe b The guard must be securely attached to the power tool and positioned for maximum safety so the least amount of wheel is exposed towards the operator The guard helps to protect operator from broken wheel fragments and accidental contact with wheel c Wheels must be used only for recommended applications For example do not grind with the side of cut off wheel Abrasive cut off wheels are intended for peripheral grinding side forces applied to these wheels may cause them to shatter i Keep bystanders a safe distance away from work area Anyone entering the work area must wear personal protective equipment Fragments of workpiece or of a broken accessory may fly away and cause injury beyond immediate area of operation c Do not use accessories which are not specifically designed and recommended by the tool manufacturer Just because the accessory can be attached to your power tool it does not assure safe operation f The arbour size of wheels flanges backing pads or any other accessory must properly fit the spindle of the power tool Accessories with arbour holes that do not match the mounting hardware of the power tool will run out of balance vibrate excessively and may cause loss of control Safety Warnings Specific for Grinding and Abrasive Cutting Off Operations h Wear personal protective equipment Depending on application use face shield safety goggles or safety glasses As appropriate wear dust mask hearing protectors gloves and shop apron capable of stopping small abrasive or workpiece fragments The eye protection must be capable of stopping flying debris generated by various operations The dust mask or respirator must be capable of filtrating particles generated by your operation Prolonged exposure to high intensity noise may cause hearing loss j Hold power tool by insulated gripping surfaces only when performing an operation where the cutting accessory may contact hidden wiring or its own cord Cutting accessory contacting a live wire may make exposed metal parts of the power tool Jive and shock the operator e The outside diameter and the thickness of your accessory must be within the capacity rating of your power tool Incorrectly sized accessories cannot be adequately guarded or controlled e Do not attach a saw chain woodcarving blade or toothed saw blade Such blades create frequent kickback and loss of control d Always use undamaged wheel flanges that are of correct size and shape for your selected wheel Proper wheel flanges support the wheel thus reducing the possibility of wheel breakage Flanges for cut off wheels may be different from grinding wheel flanges e Do not use worn down wheels from larger power tools Wheel intended for larger power tool is not suitable for the higher speed of a smaller tool and may burst I Never lay the power tool down until the accessory has come to a complete stop The spinning accessory may grab the surface and pull the power tool out of your control Additional Safety Warnings Specific for Abrasive CuttingOff Operations m Do not run the power tool while carrying it at your side Accidental contact with the spinning accessory could snag your dothing pulling the accessory into your body a Do not jam the cut off wheel or apply excessive pressure Do not attempt to make an excessive depth of cut Overstressing the wheel increases the loading and susceptibility to twisting or binding of the wheel in the cut and the possibility of kickback or wheel breakage n Regularly clean the powertool s air vents The motor s fan will draw the dust inside the housing and excessive accumulation of powdered metal may cause electrical hazards b Do not position your body in line with and behind the rotating wheel When the wheel at the point of operation is moving away from your body the possible kickback may propel the spinning wheel and the power tool directly at you o Do not operate the power tool near flammable materials Sparks could ignite these materials p Do not use accessories that require liquid coolants Using water or other liquid coolants may result in electrocution or shock c When wheel is binding or when interrupting a cut for any reason switch off the power tool and hold the power tool motionless until the wheel comes to a complete stop Never attempt to remove the cut off wheel from the cut while the wheel is in motion otherwise kickback may occur Investigate and take corrective action to eliminate the cause of wheel binding d Do not restart the cutting operation in the workpiece Let the wheel reach full speed and carefully reenter the cut The wheel may bind walk up or kickback if the power tool is restarted in the workpiece e Support panels or any oversized workpiece to minimize the risk of wheel pinching and kickback Large workpieces tend to sag under their own weight Supports must be placed under the workpiece near the line of cut and near the edge of the workpiece on both sides of the wheel f Use extra caution when making a pocket cut into existing walls or other blind areas The protruding wheel may cut gas or water pipes electrical wiring or objects that can cause kickback Safety Warnings Specific for Sanding Operations a Do not use excessively oversized sanding disc paper Follow manufacturers recommendations when selecting sanding paper Larger sanding paper extending beyond the sanding pad presents a laceration hazard and may cause snagging tearing of the disc or kickback Safety Warnings Specific for Wire Brushing Operations a Be aware that wire bristles are thrown by the brush even during ordinary operation Do not overstress the wires by applying excessive load to the brush The wire bristles can easily penetrate light clothing and or skin b If the use of a guard is recommended for wire brushing do not allow any interference of the wire wheel or brush with the guard Wire wheel or brush may expand in diameter due to work load and centrifugal forces Appliances used at many different locations including open air should be connected via a residual current device of 30 mA or less Dust and splinters must not be removed while the machine is running Only plug in when machine is switched off Never reach into the danger area of the tool when it is running Always use the auxiliary handle Immediately switch off the machine in case of considerable vibrations or if other malfunctions occur Check the machine in order to find out the cause Always use and store the grinding disks according to the manufacturer s instructions When grinding metal flying sparks are produced Take care that no persons are endangered Because of the danger of fire no combustible materials should be located in the vicinity spark flight zone Do not use dust extraction Due care should be taken that no sparks or sanding dust flying from the workpiece come into contact with you When separating stone the guide shoe must be used The adjusting nut must be tightened before starting to work with the machine The workpiece must be fixed if it is not heavy enough to be steady Never lead the workpiece to the grinding disk with your hand Under extreme conditions e g smooth grinding metals with the arbour and vulcanized fibre grinding wheel significant contamination can build up on the inside of the angle grinder For safety reasons in such conditions the inside should be cleaned thoroughly of metal deposits and a motor circuit breaker must be connected in series If the motor circuit breaker trips the machine must be sent for repair For accessories intended to be fitted with threaded hole wheel ensure that the thread in the wheel is long enough to accept the spindle length For cutting or separating use a closed protection cap available as an accessory ENGLISH 21
