Skil 1490 NA [7/112] Application advice

- check the tight seating of the accessory (incorrect

or not securely fastened accessories can come loose

during operation and create a hazard)

• Mounting of sanding sheet 5

- knock the dust out of the VELCRO material on sanding

pad C 2 before mounting the sanding sheet

- mount VELCRO sanding sheet as illustrated

! the dust suction requires the use of perforated

sanding sheets

! perforation in sanding sheet should correspond

with perforation in sanding foot

! replace worn sanding sheets in time

! always use the tool with the total VELCRO

surface covered with sanding paper

• Dust/chip extraction 6

- mount dust extraction device D as illustrated

- connect vacuum cleaner

! do not use dust extraction device/vacuum cleaner

when sanding metal

- clean dust extraction device D regularly for optimal

dust pick-up performance

• On/o

- switch on/o the tool by pushing switch E 2 in "I"/"O"

position

! before the accessory reaches the workpiece, the

tool should run at full speed

! before switching off the tool, you should lift it

from the workpiece

• Adjusting working speed 7

- with wheel F the required oscillating frequency can be

adjusted from low (1) to high (6) (also while tool is

running)

- the optimal working speed depends on the material

and can be determined with practical trials

• Holding and guiding the tool

! while working, always hold the tool at the

grey-coloured grip area(s) 8

- keep ventilation slots G 2 uncovered

- do not apply too much presssure on the tool

(excessive pressure will cause excessive heat and

may shorten the service life of the accessory)

APPLICATION ADVICE

• Use segment saw blade H 2 for separating and plunge

cuts in wood, plaster, gypsum and plastics (also for

sawing close to edges, in corners and other hard-to-

reach areas)

• Use plunge-cut saw blade J 2 for separating and deep

plunge cuts in ferrous and non-ferrous metals

• Use plunge-cut saw blade K 2 for smaller separating

and plunge cuts in ferrous and non-ferrous metals

• Use plunge-cut saw blade L 2 for separating and deep

plunge-cuts in wood, plaster, gypsum and soft plastics

(also for sawing close to edges, in corners and other

hard-to-reach areas)

• Use plunge-cut saw blade M 2 for smaller separating

and plunge-cuts in wood, plaster, gypsum and soft

plastics

MAINTENANCE / SERVICE

• Always keep tool and cord clean (especially ventilation

slots G 2)

! disconnect the plug before cleaning

• If the tool should fail despite the care taken in

manufacturing and testing procedures, repair should be

carried out by an after-sales service centre for SKIL

power tools

- send the tool undismantled together with proof of

purchase to your dealer or the nearest SKIL service

station (addresses as well as the service diagram of

the tool are listed on www.skilmasters.com)

ENVIRONMENT

• Do not dispose of electric tools, accessories and

packaging together with household waste material

(only for EU countries)

- in observance of European Directive 2012/19/EC on

waste of electric and electronic equipment and its

implementation in accordance with national law,

electric tools that have reached the end of their life

must be collected separately and returned to an

environmentally compatible recycling facility

- symbol 9 will remind you of this when the need for

disposing occurs

DECLARATION OF CONFORMITY

• We declare under our sole responsibility that the product

described under “Technical data” is in conformity with the

following standards or standardization documents: EN

60745, EN 61000, EN 55014, in accordance with the

provisions of the directives 2004/108/EC, 2006/42/EC,

2011/65/EU

• Technical file at: SKIL Europe BV (PT-SEU/ENG1),

4825 BD Breda, NL

¹ÊÁÂÆÎ¹Æ¼½ÊÇÇ¾¼½Æ

È½Ê¹ÌÁÇÆËŵÆ¿ÁÆ½½ÊÁÆ¿

ÍÊÇÈ½Ɠˁ˅ʿ˂Ê½¼¹Ɠ

Ä¹¾ÁÂÃ¿Ê¹¹¾

ÈÈÊÇÎ¹Ä¹Æ¹¿½Ê

23.12.2013

NOISE/VIBRATION

• Measured in accordance with EN 60745 the sound

pressure level of this tool is 85 dB(A) and the sound

power level 96 dB(A) (standard deviation: 3 dB), and the

vibration ✱ (hand-arm method)

✱ when surface grinding 4.1 m/s² (uncertainty K = 1.5 m/s²)

✱ when cutting with plunge-cut saw blade 7.4 m/s²

(uncertainty K = 1.5 m/s²)

✱ when cutting with segment saw blade 7.1 m/s²

(uncertainty K = 1.5 m/s²)

• The vibration emission level has been measured in

accordance with a standardised test given in EN 60745; it

may be used to compare one tool with another and as a

preliminary assessment of exposure to vibration when

using the tool for the applications mentioned
