PE5T User Manual
2
feature provides a faster response time to recover servers and other devices
when a circuit overload causes a loss of power.
With its advanced security features and ease of operation, the eco PDU is the
most convenient, most reliable, and most cost effective way to remotely
monitor power and allocate power resources in the most efficient way possible.
Note: 1. Sensors are optional accessories. A sensor-enabled installation is
required to generate a more complete energy-efficient data and chart.
Higher sensor installation density is helpful to generate more accurate
data. See Optional Accessories, page 7, for further information.
2. Circuit breaker monitoring is only available on models with 30/32
amps.
3. eco PDUs are primarily designed for access via Intranets; extra
network security protection is suggested for Internet access usage.
