PE5T User Manual
76
PE5342TG
Function PE5342TG
Power Outlets Direct 42
Connectors Power Cord 1 x IEC 60309 32A
Power Outlets Total: 36 x IEC320 C13 + 6 x IEC320 C19
Bank 1: Outlet 1–21; 18 x C13 + 3 x C19
Bank 2: Outlet 22–42; 18 x C13 + 3 x C19
Sensor 2 x RJ-11
LAN 1 x RJ-45 Female (Silver) + LEDs (Orange/Green)
LEDs PDU/Phase / Bank 1 digit 7-segment (Orange)
PDU/Phase / Bank / IP 3 (Green)
Current / IP Address 3-digit 7-segment (Orange)
Output Power Indicator 2 (Red)
Power 1 (Blue)
LAN 10/100M 1 (Orange / Green)
Link 1 (Green)
Sensor 2 (Green)
Switches Reset 1 x Semi-recessed Pushbutton
Power 2 x 16A Slim Breakers
Button 1 x Pushbutton
I/P Rating 100–240V~; 50–60Hz; 32A (Max)
Power Capacity 7360 VA (Max)
O/P Rating Per Port C13 Duplex Receptacles: 10A (Max)
C19 16A (Max)
Per Bank 16 (Max)
Total 32A (Max)
Environment Operating Temperature
0–40
o
C
Storage Temperature
-20–60
o
C
Humidity 0–80% RH Non-condensing
Physical
Properties
Housing Metal
Weight 5.57 kg
Dimensions (L x W x H) 177.5 x 5.6 x 4.8 cm
