Chapter 1. Introduction

Note: Holes for ATEN Lok-U-Plug cable holders are located around the

sockets. See Securing the Cables / Plugs, page 23, for further

information.

No. Item Description

1 power cord This is the power cord that connects the unit to an

AC power source via IEC 60309 32A plug.

2 circuit breakers (Bank 1

and Bank 2)

2 x 16A slim breakers. As a safety measure, if

there is an overcurrent situation regarding the

device’s power, the circuit breakers will trip. Push

the switch back to recover normal operation.

3 power outlets* 42 in Total (36 x IEC320 C13 + 6 x IEC320 C19)

4 sensor ports External sensors plug into these two RJ-11 ports.

5 LAN port and LEDs The cable that connects the eco PDU to the LAN

plugs in here. The link and LAN LEDs are built into

the LAN port:

Link: Lights green to indicate that a connection via

the eco PDU's RJ-45 Ethernet port has been

established. Flashes to indicate data is being

transmitted.

LAN: Lights orange to indicate 10 Mbps data

transmission speed. The LED lights green to

indicate 100 Mbps data transmission speed.

6 readout section, LEDs

and reset button

Details of this section are provided on page 18.
