Aten PE5342TG [65/88] Importing the private certificate

Chapter 4. Browser Operation

Importing the Private Certificate

To import the private certificate, do the following:

1. Click Browse to the right of Private Key; browse to where your private

encryption key file is located; and select it.

2. Click Browse to the right of Certificate; browse to where your certificate

file is located; and select it.

3. Click Upload to complete the procedure.

Note: 1. Clicking Restore Default returns the device to using the default

ATEN certificate.

2. Both the private encryption key and the signed certificate must be

imported at the same time.

When you have finished making your settings on this page, click Save.
