PE5T User Manual
70
PE5224TA
Function PE5224TA
Power Outlets Direct 24
Connectors Power Inlet 1 x NEMA 5-20P
Power Outlets Total: 24 x NEMA 5-20R
Sensor 2 x RJ-11
LAN 1 x RJ-45 Female (Silver) + LEDs (Orange/Green)
LEDs PDU/Phase / Bank 1 digit 7-segment (Orange)
PDU/Phase / Bank / IP 3 (Green)
Current / IP Address 3-digit 7-segment (Orange)
Output Power Indicator 1 (Red)
Power 1 (Blue)
LAN 10/100M 1 (Orange / Green)
Link 1 (Green)
Sensor 2 (Green)
Switches Reset 1 x Semi-recessed Pushbutton
Button 1 x Pushbutton
I/P Rating 100–120V~; 50-60 Hz; 20A (Max); 16A (UL de-rated)
Power Capacity 2400 VA (Max); 1920 VA (UL de-rated)
O/P Rating Per Port NEMA 5-20R: 20A (Max); 16A(UL de-rated)
Per Bank 20A (Max); 16A (UL de-rated)
Total 20A (Max); 16A (UL de-rated)
Environment Operating Temperature
0–50
o
C
Storage Temperature
-20–60
o
C
Humidity 0–80% RH Non-condensing
Physical
Properties
Housing Metal
Weight 3.93 kg
Dimensions (L x W x H) 177.5 x 5.6 x 4.8 cm
