Chapter 1. Introduction
9
Note: Holes for ATEN Lok-U-Plug cable holders are located around the
outlets. See Securing the Cables / Plugs, page 23, for further
information.
No. Item Description
1 power inlet The power cord that connects the unit to an AC
power source plugs into this IEC 60320 C20
socket.
2 power outlets* 21 in total (18 x IEC320 C13 + 3 x IEC320 C19)
3 sensor ports External sensors plug into these two RJ-11 ports.
4 LAN port and LEDs The cable that connects the eco PDU to the LAN
plugs in here. The link and LAN LEDs are built into
the LAN port:
Link: Lights green to indicate that a connection via
the eco PDU's RJ-45 Ethernet port has been
established. Flashes to indicate data is being
transmitted.
LAN: Lights orange to indicate 10 Mbps data
transmission speed. The LED lights green to
indicate 100 Mbps data transmission speed.
5 readout section, LEDs
and reset button
Details of this section are provided on page 18.
