X:SUB218AMP-CONTROLS&CONNECTIONS
1. POWER: Switches the power on/off.
2. Status LEDs:
- Prot.: indicates that the internal amplifier switched to protection mode due to a fault
of the amplifier itself or of the connected speakers (please call the technical support)
- Comp.: indicates activity of the compressor. If the signal passes over a safety thresh-
old, the compressor guarantees a good quality playback without acoustic distortion,
damping the appropriate signal frequencies. The system operates in total safety. If the
LED is constantly On, there is an excess of signal. In this case, please reduce the in-
coming signal level.
- Sign.: flashes when signal is incoming.
- Temp.: indicates that the internal amplifier switched to protection mode due to
excessive heating. In this condition, the amplifier supplies half the normal
power. Please reduce the input signal to allow the restore of normal load condi-
tions.
3. LED-lighting switches:
- Phase: inverts the phase of the input signal.
- User: activates the User preset (to be configured with the D:SP Editor)
4. LEVEL: adjusts the input signal level.
5. In & Out RS-485 Etherconn: Etherconn connectors to connect to the digital network.
Connect every RS485 OUT to the RS485 IN input of the next speaker along the daisy
chain. The RS-485 IN of the first speaker in the array must be connected to the USB-
485 interface (D:SP INTERFACE) output.
6. Input section:
- L&R INPUT: XLR input socket for connection of the signal to be amplified.
- L&R LINK: sends to the output the same signal coming from LEFT/RIGHT INPUT
connector. This allow the cascade connection of different devices to the same sound
source.
7. OUT-BOX: Speakon connector to feed the X:SIDER with the driving signal. Do not at-
tempt to provide this signal to a X:SIDER 15 speaker.
8. AC-IN: connects to the mains.
9. AC-OUT: easily connects another VERSE speaker to the mains. Do not exceed current
limits. Powercon cables cannot supply more than 16A and X:SUB 218 AMP approxi-
mately draw 6A, hence the AC-OUT of a X:SUB 218 AMP cannot supply more than 10A
total.
EENN
X:SIDER - User’s Guide
9
