VERSE XSIDER 15 [50/56] Technical specifications
![VERSE XSIDER 15 [50/56] Technical specifications](/views2/2007783/page50/bg32.png)
TECHNICALSPECIFICATIONS
SPEAKER X:SIDER 15 X:SUB 218
Frequency Range 53Hz - 20Khz 35Hz - 110Hz
Max SPL (calculated) 128dB (cont.), 134dB (peak) 138dB (cont.), 144dB (peak)
Dispersion Angle (VxH)
60°x40° (1 enclosure), 60°x76° (2 enclosures),
60°x116° (3 enclosures) N/A
WOOFER
Nominal Diameter 15" 2 x 18"
Sensitivity (1W/1m) 98 dB 98 dB each one
Impedance 8 Ohm 2x16 Ohm in parallel
Continuous Power Handling 1600 Watt 2 x 2400 Watt
Magnet neodymium neodymium
Voice Coil 4" aluminium 4" copper
Former glass fibre glass fibre
TWEETER
Throat Diameter 1.5" N/A
Sensitivity (1W/1m) 108 dB N/A
Impedance 16 Ohm N/A
Continuous Power Handling 160 Watt N/A
Magnet ceramic N/A
Voice Coil 3" aluminium N/A
Diaphragm titanium N/A
Protections HP filter 6 dB/oct, PTC N/A
CONSTRUCTION
Cabinet 18 mm laminated birch plywood 21 mm laminated birch plywood
Finish black scratch resistant paint black scratch resistant paint
Protection metal grid metal grid
Dimensions (HxWxD) 700 x 460 x 410 mm 570 x 1300 x 700 mm
Flying system built in suspension system
Accessories (optional)
rigging accessory for flying two X:SIDER15,
rigging accessory for flying three X:SIDER15
3 stand adaptors, removable rear dolly with
casters
Weight 35 Kg 83 Kg (without removable dolly)
CONNECTORS
Speakon
1 Neutrik Speakon NL4MP: 1+ Low+, 1- Low-,
2+ High+, 2- High-
1 Neutrik Speakon NL8MPR: 1+/2+ IN+, 1-/2-
IN-
AMPLIFIER X:SIDER 15 AMP X:SUB 218 AMP
Output Power
2 x 1050 Watt @ 8ohm (EIAJ test - 1kHz, 1%
THD) 2 x 570 Watt @ 16ohm (EIAJ test - 1kHz,
1% THD)
1 x 3400 Watt @ 8ohm (EIAJ test - 1kHz, 1%
THD), bridged mode (EIAJ test - 1kHz, 1% THD)
Power Requirements
AC 195V - 250V, 50/60 Hz; I nom.=2.9A rms
(1/8 max output power), AC 95V - 125V, 50/60
Hz; I nom.=5.5A rms (1/8 max output power) AC 85V - 270V, 50/60 Hz with PFC
Consumption 410VA (1/8 max output power @ 16 ohm) 900 VA (1/8 max output power @ 8 ohm)
Damping factor 20 Hz - 1000 Hz > 200 @100 Hz > 500
Distortion <0.5% (THD, DIM, SMPTE) <0.5% (THD, DIM, SMPTE)
Active protective circuitry
power limiting, thermal shutdown, short-circuit /
overload output protection
power limiting, thermal shutdown, short-circuit /
overload output protection
PREAMPLIFIER
Description
DSP based (eq., x-over, comp, delay, limit), 24
bit convertion, 48 KHz sampling
DSP based (eq., x-over, delay, limit), 24 bit
convertion, 48 KHz sampling
Input sensitivity 0 dBu 0 dBu
Crossover frequency 1000 Hz 110 Hz
Subsonic filter yes yes
Nominal inpedance 15 kOhm balanced to ground 15 kOhm balanced to ground
DIMENSIONS
H x W x D 88 (2U) x 241.5 x 350 mm 88 (2U) x 483 x 350 mm
Weight 5 Kg 8.5 Kg
CONTROL PANEL
Level from -Inf to 0 Db from -Inf to 0 Db
Controls
CLUSTER (for use side by side), H. PASS (high
pass filter), USER PHASE (for inverting phase), USER
Indication leds
1 green led = On/Off, 2 green leds = Signal on
low/high, 2 red leds = Compression low/high, 2
red leds = Protection low/high, 1 red led =
Temperature
1 green led = On/Off, 1 green led = Signal on, 1
red led = Compression, 1 red led = Protection, 1
red led = Temperature
CONNECTORS
Connectors
1 XLR female input signal, 1 XLR male link
signal, 2 RJ45 input/output RS485, 1 Neutrik
Speakon NL4MP: 1+ Low+, 1- Low-, 2+ High+,
2- High-, 1 Neutrik Powercon NAC3MPA AC IN,
1 Neutrik Powercon NAC3MPB AC OUT
2 XLR female input signal left/right, 2 XLR male
link signal left/right, 2 RJ45 input/output RS485,
1 Neutrik Speakon NL8MP: 1+/2+ OUT+, 1-/2-
OUT-, 1 Neutrik Powercon NAC3MPA AC IN, 1
Neutrik Powercon NAC3MPB AC OUT
X:SIDER - Technical Outline - Prospetto Tecnico
TTCC
48
