AMERICAN DJ Vizi Beam RXONE [10/22] Channel value function
![AMERICAN DJ Vizi Beam RXONE [10/22] Channel value function](/views2/2008177/page10/bga.png)
ADJ Products, LLC - www.adj.com - Vizi Beam RXONE Instruction Manual Page 19ADJ Products, LLC - www.adj.com - Vizi Beam RXONE Instruction Manual Page 18
Vizi Beam RXONE 15 Channel Mode
Channel Value Function
8 PRISM ROTATION
0 - 127 INDEXING
128 - 190 CLOCKWISE ROTATION FAST - SLOW
191 - 192 NO ROTATION
193 - 255 COUNTER-CLOCKWISE ROTATION SLOW - FAST
9 FROST
0 - 7 NO FUNCTION
8 - 255 0% - 100%
10 PAN/TILT MACROS
0 - 7 OFF
8 - 15 MACRO 1
16 - 23 MACRO 2
24 - 31 MACRO 3
32 - 39 MACRO 4
40 - 47 MACRO 5
48 - 55 MACRO 6
56 - 63 MACRO 7
64 - 71 MACRO 8
72 - 79 MACRO 9
80 - 87 MACRO 10
88 - 95 MACRO 11
96 - 103 MACRO 12
104 - 111 MACRO 13
112 - 119 MACRO 14
120 - 127 MACRO 15
128 - 135 MACRO 16
136 - 143 MACRO 17
144 - 151 MACRO 18
152 - 159 MACRO 19
160 - 167 MACRO 20
168 - 175 MACRO 21
176 - 183 MACRO 22
184 - 191 MACRO 23
192 - 199 MACRO 24
200 - 207 MACRO 25
208 - 215 MACRO 26
216 - 223 MACRO 27
224 - 231 MACRO 28
232 - 239 MACRO 29
240 - 247 MACRO 30
248 - 255 MACRO 31
Vizi Beam RXONE 15 Channel Mode
Channel Value Function
5 SHUTTER & STROBE
0 - 7 SHUTTER CLOSED
8 - 15 SHUTTER OPEN
16 - 131 STROBING SLOW - FAST
132 - 167 SLOW OPEN - FAST CLOSE
168 - 203 FAST CLOSE - SLOW OPEN
204 - 239 FAST OPEN - SLOW CLOSE
240 - 247 RANDOM STROBE
248 - 255 OPEN
6 0 - 255 MASTER DIMMER 0% - 100%
7 PRISM
0 - 7 OPEN
8 - 127 PRISM ROTATION
128 - 132 PRISM ROTATION EFFECT 1
133 - 137 PRISM ROTATION EFFECT 2
138 - 141 PRISM ROTATION EFFECT 3
142 - 146 PRISM ROTATION EFFECT 4
147 - 150 PRISM ROTATION EFFECT 5
151 - 155 PRISM ROTATION EFFECT 6
156 - 159 PRISM ROTATION EFFECT 7
160 - 164 PRISM ROTATION EFFECT 8
165 - 168 PRISM ROTATION EFFECT 9
169 - 173 PRISM ROTATION EFFECT 10
174 - 177 PRISM ROTATION EFFECT 11
178 - 182 PRISM ROTATION EFFECT 12
183 - 187 PRISM ROTATION EFFECT 13
188 - 191 PRISM ROTATION EFFECT 14
192 - 196 PRISM ROTATION EFFECT 15
197 - 200 PRISM ROTATION EFFECT 16
201 - 205 PRISM ROTATION EFFECT 17
206 - 209 PRISM ROTATION EFFECT 18
210 - 214 PRISM ROTATION EFFECT 19
215 - 218 PRISM ROTATION EFFECT 20
219 - 223 PRISM ROTATION EFFECT 21
224 - 227 PRISM ROTATION EFFECT 22
228 - 232 PRISM ROTATION EFFECT 23
233 - 236 PRISM ROTATION EFFECT 24
237 - 241 PRISM ROTATION EFFECT 25
242 - 246 PRISM ROTATION EFFECT 26
247 - 250 PRISM ROTATION EFFECT 27
251 - 255 PRISM ROTATION EFFECT 28
