![AMERICAN DJ Vizi Beam RXONE [4/22] Caution](/views2/2008177/page4/bg4.png)
ADJ Products, LLC - www.adj.com - Vizi Beam RXONE Instruction Manual Page 7
ADJ Products, LLC - www.adj.com - Vizi Beam RXONE Instruction Manual Page 6
Vizi Beam RXONE Important Discharge Lamp Warnings
This fixture is fitted with a discharge lamp which is highly susceptible to
damage if improperly handled. NEVER touch the lamp located within the
reflector with your bare fingers as the oil from your hands will shorten lamp
life. Also, never move the fixture until the lamps have had ample time to cool.
Remember, lamps are not covered under warranty conditions.
This unit emits intense UV radiation which is harmful to the eyes and skin.
The intense luminance of the lamp can cause severe damage to the retina.
Never operate this unit without it’s covers, these covers have been specially
designed to shield against UV radiation.
Epileptic Warning: Those suering from epilepsy should avoid looking directly
into the lamp at all times.
Avoid switching the xture on and o repeatedly in short intervals as this will
reduce lamp life and intensity.
To achieve the intensity associated with discharge lamps, these lamps use
gas sealed in a high pressure environment to emit a brilliant output. Due to
the high pressure involved with the construction of the lamp, the lamp may
explode during prolonged extensive use. This risk is increased with age,
added care is encouraged when dealing with older lamps. Extreme caution
should be used when operating this or any xture tted with a gas discharge
lamp. Never open this unit while in use.
VERY IMPORTANT: This is for your safety and the life length of the unit.
The Osram® 1R Discharge lamp has lifetime of 6000 hours.
ADJ recommends periodically checking the lamp running time (see page 30
“Lamp Time”). When the lamp reaches the 6000 hour mark, or close to it, we
strongly suggest you switch the lamp out.
Replace the lamp following the instructions on pages 37-38. After replace-
ing the lamp you must clear the LAMP RUNNING TIME (see page 30 “Lamp
Time”).
Warning: DO NOT use this lamp more then 6000 hours. Using the lamp
any longer then the set life could seriously damage your unit.
WARNING! CAUTION! FIRE HAZARD! DUE TO THE EXTREME
HEAT CAUSED BY THIS LAMP, THE MINIMUM DISTANCE TO
LIGHTED OBJECTS IS 8 METERS (26FT).
The Vizi Beam RXONE carries a one year limited warranty. Please fill
out the enclosed warranty card to validate your purchase. All returned
service items whether under warranty or not, must be freight pre-
paid and accompany a return authorization (R.A.) number. The R.A.
number must be clearly written on the outside of the return package.
A brief description of the problem as well as the R.A. number must
also be written down on a piece of paper and included in the shipping
carton. If the unit is under warranty, you must provide a copy of your
proof of purchase invoice. You may obtain a R.A. number by con-
tacting our customer support team on our toll free customer support
number. All packages returned to the service department not display-
ing a R.A. number on the outside of the package will be returned to
the shipper at the shippers cost.
Vizi Beam RXONE Product
Registration
To optimize the performance of this product, please read these operating
instructions carefully to familiarize yourself with the basic operations of
this unit. These instructions contain important safety information regard-
ing the use and maintenance of this unit. Please keep this manual with
the unit, for future reference.
Vizi Beam RXONE General Instructions
Caution! There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures
warranty. In the unlikely event your unit may require service please
contact ADJ®.
During operation the housing may become extremely hot. Avoid touch-
ing the unit with bare hands while in use.
ADJ
® will not accept any liability for any resulting damages caused by
the non-observance of this manual or any unauthorized modication
to this unit.
Vizi Beam RXONE Handling Precautions
Содержание
- User instructions 1
- Vizi beam rxone 1
- Customer support 2
- Introduction 2
- Table of contents 2
- Unpacking 2
- Unpacking introduction customer support safety precautions features handling precautions registration important discharge lamp warnings fire warning mounting 9 cad drawing 0 photometric chart 0 base layout 1 dmx set up 2 14 power cord daisy chain 4 dmx control 5 dmx traits 6 25 system menu 6 32 offset menu 2 33 fuse replacement 6 lamp replacement 6 38 cleaning 9 trouble shooting 9 warranty 0 specifications 2 2
- Vizi beam rxone 2
- Warning 2
- Caution 4
- Very important 4
- Notice the suitable enviromental temperature for this light ing fixture is between 25 c to 45 c do not place this lighting fixture in an enviroment where the temperatures are under or above the temperatures stated above this will allow the fixture to run at its best and help prolong the fixture life 5
- Screw one clamp via a m12 screw and nut onto the omega holders insert the quick lock fasteners of the first omega holder into the respective holes on the bottom of the vizi beam rxone tighten the quick lock fasteners fully clockwise pull the safety cable through the openings located on the base plate and over the trussing system or a safe fixation spot insert the end in the carabine and tighten the safety screw 5
- Mm 15 2 6
- Mm 8 5 6
- Vizi beam rxone base layout 6
- Vizi beam rxone cad drawing 6
- Vizi beam rxone photometric chart 6
- Dmx 512 7
- Notice 7
- Power supply 7
- Special note line termination 7
- Pin xlr dmx connectors 8
- Universal dmx control 8
- Channel value function 9
- Gobo s 9
- Vizi beam rxone 15 channel mode 9
- Channel value function 10
- Vizi beam rxone 15 channel mode 10
- Channel value function 11
- Vizi beam rxone 15 channel mode 11
- Vizi beam rxone 17 channel mode 11
- Channel value function 12
- Gobo s 12
- Vizi beam rxone 17 channel mode 12
- Channel value function 13
- Vizi beam rxone 17 channel mode 13
- Channel mod 14
- Dmx addres 14
- Show mod 14
- Dmx last stat 15
- Pan inver 15
- Slave mode 15
- Sound sens 15
- Sound stat 15
- Tilt inver 15
- Auto tes 16
- Back ligh 16
- Factory restor 16
- Firmware versio 16
- Fixture tim 16
- Lamp o 16
- Lamp power o 16
- Lamp tim 16
- Adjustment of the pan home position 17
- Adjustment of the tilt home position 17
- Press the menu button until reset is displayed press enter 17
- Setting adjustment for the 1st prism 17
- Setting adjustment for the color wheel 17
- Setting adjustment for the gobo wheel 17
- Setting adjustment for the shutter 17
- The fixture will now reset 17
- Until yes is displayed press enter to confim if you do not wish restore the settings select no and press enter 17
- Use this function to reset the motors 17
- Master slave operation 18
- Show mode 18
- Sound active mode 18
- Caution 19
- Fuse replacement 19
- Lamp replacement 19
- Replacing the lamp is relatively easy unplug the unit from its power source allow the unit 15 minutes to cool down remove the shell that says lamp access on the rear start by unscrewing the four phillips screws that hold the shell in place once the screws are unscrewed remove the shell you will now have access to the lamp 19
- Warning 19
- Carefully disconnect the two wires that are connected to the lamp s reflector firmly grab the moving head to hold it in place gently press the lamp down and gently pull the top of the lamp out of the lamp holder note never touch the lamp located within the reflector with your bare hands 20
- Fixture cleaning 20
- Replace the lamp by setting the lamp into the two bottom brakets gently press the lamp down and insert the top of the lamp into the lamp frame 20
- Adj products llc www adj com vizi beam rxone instruction manual page 40 adj products llc www adj com vizi beam rxone instruction manual page 41 21
- Vizi beam rxone notes 21
- Vizi beam rxone warranty 21
- Adj products llc 6122 s eastern ave los angeles ca 90040 usa tel 323 582 2650 fax 323 725 6100 web www adj com e mail info americandj com a d j supply europe b v junostraat 2 6468 ew kerkrade the netherlands service adjgroup eu www adj eu tel 31 45 546 85 00 fax 31 45 546 85 99 22
- Auto sensing voltage 22
- Model vizi beam rxone 22
- Please note 22
- Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice 22
