AMERICAN DJ Vizi Beam RXONE [9/22] Channel value function
![AMERICAN DJ Vizi Beam RXONE [9/22] Channel value function](/views2/2008177/page9/bg9.png)
ADJ Products, LLC - www.adj.com - Vizi Beam RXONE Instruction Manual Page 17ADJ Products, LLC - www.adj.com - Vizi Beam RXONE Instruction Manual Page 16
Vizi Beam RXONE 15 Channel Mode
Channel Value Function
1 0 - 255 PAN MOVEMENT
2 0 - 255 TILT MOVEMENT
3 COLOR WHEEL
0 - 2 WHITE
3 - 4 WHITE & RED
5 - 6 RED
7 - 8 RED & BLUE
9 - 10 BLUE
11 - 12 BLUE & GREEN
13 - 14 GREEN
15 - 16 GREEN & LIGHT YELLOW
17 - 18 LIGHT YELLOW
19 - 21 LIGHT YELLOW & ORANGE
22 - 23 ORANGE
24 - 25 ORANGE & MAGENTA
26 - 27 MAGENTA
28 - 29 MAGENTA & LIGHT BLUE
30 - 31 LIGHT BLUE
32 - 33 LIGHT BLUE & YELLOW
34 - 35 YELLOW
36 - 37 YELLOW & LIGHT GREEN
38 - 39 LIGHT GREEN
40 - 42 LIGHT GREEN & PURPLE
43 - 44 PURPLE
45 - 46 PURPLE & PINK
47 - 48 PINK
49 - 50 PINK & MEDIUM YELLOW
51 - 52 MEDIUM YELLOW
53 - 54 MEDIUM YELLOW & CTB
55 - 56 CTB
57 - 58 CTB & UV
59 - 60 UV
61 - 63 UV & WHITE
64 - 127 OPEN
128 - 189 CLOCKWISE ROTATION FAST - SLOW
190 - 193 NO ROTATION
194 - 255 COUNTER-CLOCKWISE ROTATION SLOW - FAST
Vizi Beam RXONE 15 Channel Mode
Channel Value Function
4 GOBO WHEEL
0 - 3 OPEN
4 - 7 GOBO 1
8 - 11 GOBO 2
12 - 15 GOBO 3
16 - 19 GOBO 4
20 - 23 GOBO 5
24 - 27 GOBO 6
28 - 31 GOBO 7
32 - 35 GOBO 8
36 - 39 GOBO 9
40 - 43 GOBO 10
44 - 47 GOBO 11
48 - 51 GOBO 12
52 - 55 GOBO 13
56 - 59 GOBO 14
60 - 63 GOBO 15
64 - 68 GOBO 1 SHAKE
69 - 72 GOBO 2 SHAKE
73 - 76 GOBO 3 SHAKE
77 - 80 GOBO 4 SHAKE
81 - 84 GOBO 5 SHAKE
85 - 89 GOBO 6 SHAKE
90 - 93 GOBO 7 SHAKE
94 - 97 GOBO 8 SHAKE
98 - 101 GOBO 9 SHAKE
102 - 105 GOBO 10 SHAKE
106 - 110 GOBO 11 SHAKE
111 - 114 GOBO 12 SHAKE
115 - 118 GOBO 13 SHAKE
119 - 122 GOBO 14 SHAKE
123 - 127 GOBO 15 SHAKE
128 - 189 COUNTER-CLOCKWISE ROTATION FAST - SLOW
190 - 193 NO ROTATION
194 - 255 CLOCKWISE ROTATION SLOW - FAST
Gobo’s
