ADJ Products, LLC - www.adj.com - Vizi Beam RXONE Instruction Manual Page 25ADJ Products, LLC - www.adj.com - Vizi Beam RXONE Instruction Manual Page 24
Vizi Beam RXONE 17 Channel Mode
Channel Value Function
10 PRISM ROTATION
0 - 127 INDEXING
128 - 190 CLOCKWISE ROTATION FAST - SLOW
191 - 192 NO ROTATION
193 - 255 COUNTER-CLOCKWISE ROTATION SLOW - FAST
11 FROST
0 - 7 NO FUNCTION
8 - 255 0% - 100%
12 PAN/TILT MACROS
0 - 7 OFF
8 - 15 MACRO 1
16 - 23 MACRO 2
24 - 31 MACRO 3
32 - 39 MACRO 4
40 - 47 MACRO 5
48 - 55 MACRO 6
56 - 63 MACRO 7
64 - 71 MACRO 8
72 - 79 MACRO 9
80 - 87 MACRO 10
88 - 95 MACRO 11
96 - 103 MACRO 12
104 - 111 MACRO 13
112 - 119 MACRO 14
120 - 127 MACRO 15
128 - 135 MACRO 16
136 - 143 MACRO 17
144 - 151 MACRO 18
152 - 159 MACRO 19
160 - 167 MACRO 20
168 - 175 MACRO 21
176 - 183 MACRO 22
184 - 191 MACRO 23
192 - 199 MACRO 24
200 - 207 MACRO 25
208 - 215 MACRO 26
216 - 223 MACRO 27
224 - 231 MACRO 28
232 - 239 MACRO 29
240 - 247 MACRO 30
248 - 255 MACRO 31
Vizi Beam RXONE 17 Channel Mode
Channel Value Function
13 PAN/TILT MACRO SPEED
0 - 255 FAST - SLOW
14 COLOR TIME
0 - 254 FAST - SLOW
255 FAST
15 GOBO TIME
0 - 254 FAST - SLOW
255 FAST
16 PAN/TILT SPEED
0 - 255 FAST - SLOW
17 SPECIAL FUNCTIONS
0 - 49 NO FUNCTION
50 - 59 PAN/TILT FAST MODE
60 - 69 PAN/TILT NORMAL MODE
70 - 79 ENABLE BLACKOUT WITH PAN/TILT MOVEMENT
80 - 89 DISABLE BLACKOUT WITH PAN/TILT MOVEMENT
90 - 99 ENABLE BLACKOUT WITH COLOR CHANGE
100 - 109 DISABLE BLACKOUT WITH COLOR CHANGE
110 - 119 ENABLE BLACKOUT WITH GOBO CHANGE
120 - 129 DISABLE BLACKOUT WITH GOBO CHANGE
130 - 139 LAMP ON
140 - 149 PAN/TILT MOTOR RESET
150 - 159 COLOR MOTOR RESET
160 - 169 GOBO MOTOR RESET
170 - 179 SHUTTER/PRISM/R PRISM/FROST RESET
180 - 199 NO FUNCTION
200 - 209 RESET ALL
210 - 219 ENABLE BLACKOUT WITH PAN/TILT/GOBO/
COLOR CHANGE
220 - 229 DISABLE BLACKOUT WITH PAN/TILT/GOBO/
COLOR CHANGE
230 - 239 LAMP OFF
240 - 255 NO FUNCTION
