Vizi Beam RXONE CAD Drawing
Vizi Beam RXONE Base Layout
1. Button:
MENU Toselecttheprogrammingfunctions
DOWN Togoforwardintheselectedfunctions
UP Togobackwardintheselectedfunctions
ENTER Toconrm theselectedfunctions
2. Microphone:Toreceivemusicforsoundactive;
3. LED:
POWER
On PowerOn
DMX
On DMXinputpresent
4. FunctionDisplay:Usedtoshowthevariousmenusandtheselectedfunction;
5. IRReceiver:ToreceivetheIRsignal;
6. Fuse:Protectstheunitfromover‐voltageorshortcircuit;
7. PowerIn/out: Usedtoconnecttosupplypower.
8. DMXIn/out: 3‐pinXLRconnectorsforDMX512operation;
279mm/11”
386.6mm/15.22”
225mm/8.85”
Vizi Beam RXONE Photometric Chart
