ADJ Products, LLC - www.adj.com - Vizi Beam RXONE Instruction Manual Page 21ADJ Products, LLC - www.adj.com - Vizi Beam RXONE Instruction Manual Page 20
Vizi Beam RXONE 17 Channel Mode
Channel Value Function
1 0 - 255 PAN MOVEMENT
2 0 - 255 PAN FINE
3 0 - 255 TILT MOVEMENT
4 0 - 255 TILT FINE
5 COLOR WHEEL
0 - 2 WHITE
3 - 4 WHITE & RED
5 - 6 RED
7 - 8 RED & BLUE
9 - 10 BLUE
11 - 12 BLUE & GREEN
13 - 14 GREEN
15 - 16 GREEN & LIGHT YELLOW
17 - 18 LIGHT YELLOW
19 - 21 LIGHT YELLOW & ORANGE
22 - 23 ORANGE
24 - 25 ORANGE & MAGENTA
26 - 27 MAGENTA
28 - 29 MAGENTA & LIGHT BLUE
30 - 31 LIGHT BLUE
32 - 33 LIGHT BLUE & YELLOW
34 - 35 YELLOW
36 - 37 YELLOW & LIGHT GREEN
38 - 39 LIGHT GREEN
40 - 42 LIGHT GREEN & PURPLE
43 - 44 PURPLE
45 - 46 PURPLE & PINK
47 - 48 PINK
49 - 50 PINK & MEDIUM YELLOW
51 - 52 MEDIUM YELLOW
53 - 54 MEDIUM YELLOW & CTB
55 - 56 CTB
57 - 58 CTB & UV
59 - 60 UV
61 - 63 UV & WHITE
64 - 127 OPEN
128 - 189 CLOCKWISE ROTATION FAST - SLOW
190 - 193 NO ROTATION
194 - 255 COUNTER-CLOCKWISE ROTATION SLOW - FAST
Vizi Beam RXONE 15 Channel Mode
Channel Value Function
11 PAN/TILT MACRO SPEED
0 - 255 FAST - SLOW
12 COLOR TIME
0 - 254 FAST - SLOW
255 FAST
13 GOBO TIME
0 - 254 FAST - SLOW
255 FAST
14 PAN/TILT SPEED
0 - 255 FAST - SLOW
15 SPECIAL FUNCTIONS
0 - 49 NO FUNCTION
50 - 59 PAN/TILT FAST MODE
60 - 69 PAN/TILT NORMAL MODE
70 - 79 ENABLE BLACKOUT WITH PAN/TILT MOVEMENT
80 - 89 DISABLE BLACKOUT WITH PAN/TILT MOVEMENT
90 - 99 ENABLE BLACKOUT WITH COLOR CHANGE
100 - 109 DISABLE BLACKOUT WITH COLOR CHANGE
110 - 119 ENABLE BLACKOUT WITH GOBO CHANGE
120 - 129 DISABLE BLACKOUT WITH GOBO CHANGE
130 - 139 LAMP ON
140 - 149 PAN/TILT MOTOR RESET
150 - 159 COLOR MOTOR RESET
160 - 169 GOBO MOTOR RESET
170 - 179 SHUTTER/PRISM/R PRISM/FROST RESET
180 - 199 NO FUNCTION
200 - 209 RESET ALL
210 - 219 ENABLE BLACKOUT WITH PAN/TILT/GOBO/
COLOR CHANGE
220 - 229 DISABLE BLACKOUT WITH PAN/TILT/GOBO/
COLOR CHANGE
230 - 239 LAMP OFF
240 - 255 NO FUNCTION
