AMERICAN DJ Vizi Beam RXONE [12/22] Channel value function
![AMERICAN DJ Vizi Beam RXONE [12/22] Channel value function](/views2/2008177/page12/bgc.png)
ADJ Products, LLC - www.adj.com - Vizi Beam RXONE Instruction Manual Page 23ADJ Products, LLC - www.adj.com - Vizi Beam RXONE Instruction Manual Page 22
Vizi Beam RXONE 17 Channel Mode
Channel Value Function
7 SHUTTER & STROBE
0 - 7 SHUTTER CLOSED
8 - 15 SHUTTER OPEN
16 - 131 STROBING SLOW - FAST
132 - 167 SLOW OPEN - FAST CLOSE
168 - 203 FAST CLOSE - SLOW OPEN
204 - 239 FAST OPEN - SLOW CLOSE
240 - 247 RANDOM STROBE
248 - 255 OPEN
8 0 - 255 MASTER DIMMER 0% - 100%
9 PRISM
0 - 7 OPEN
8 - 127 PRISM ROTATION
128 - 132 PRISM ROTATION EFFECT 1
133 - 137 PRISM ROTATION EFFECT 2
138 - 141 PRISM ROTATION EFFECT 3
142 - 146 PRISM ROTATION EFFECT 4
147 - 150 PRISM ROTATION EFFECT 5
151 - 155 PRISM ROTATION EFFECT 6
156 - 159 PRISM ROTATION EFFECT 7
160 - 164 PRISM ROTATION EFFECT 8
165 - 168 PRISM ROTATION EFFECT 9
169 - 173 PRISM ROTATION EFFECT 10
174 - 177 PRISM ROTATION EFFECT 11
178 - 182 PRISM ROTATION EFFECT 12
183 - 187 PRISM ROTATION EFFECT 13
188 - 191 PRISM ROTATION EFFECT 14
192 - 196 PRISM ROTATION EFFECT 15
197 - 200 PRISM ROTATION EFFECT 16
201 - 205 PRISM ROTATION EFFECT 17
206 - 209 PRISM ROTATION EFFECT 18
210 - 214 PRISM ROTATION EFFECT 19
215 - 218 PRISM ROTATION EFFECT 20
219 - 223 PRISM ROTATION EFFECT 21
224 - 227 PRISM ROTATION EFFECT 22
228 - 232 PRISM ROTATION EFFECT 23
233 - 236 PRISM ROTATION EFFECT 24
237 - 241 PRISM ROTATION EFFECT 25
242 - 246 PRISM ROTATION EFFECT 26
247 - 250 PRISM ROTATION EFFECT 27
251 - 255 PRISM ROTATION EFFECT 28
Vizi Beam RXONE 17 Channel Mode
Channel Value Function
6 GOBO WHEEL
0 - 3 OPEN
4 - 7 GOBO 1
8 - 11 GOBO 2
12 - 15 GOBO 3
16 - 19 GOBO 4
20 - 23 GOBO 5
24 - 27 GOBO 6
28 - 31 GOBO 7
32 - 35 GOBO 8
36 - 39 GOBO 9
40 - 43 GOBO 10
44 - 47 GOBO 11
48 - 51 GOBO 12
52 - 55 GOBO 13
56 - 59 GOBO 14
60 - 63 GOBO 15
64 - 68 GOBO 1 SHAKE
69 - 72 GOBO 2 SHAKE
73 - 76 GOBO 3 SHAKE
77 - 80 GOBO 4 SHAKE
81 - 84 GOBO 5 SHAKE
85 - 89 GOBO 6 SHAKE
90 - 93 GOBO 7 SHAKE
94 - 97 GOBO 8 SHAKE
98 - 101 GOBO 9 SHAKE
102 - 105 GOBO 10 SHAKE
106 - 110 GOBO 11 SHAKE
111 - 114 GOBO 12 SHAKE
115 - 118 GOBO 13 SHAKE
119 - 122 GOBO 14 SHAKE
123 - 127 GOBO 15 SHAKE
128 - 189 COUNTER-CLOCKWISE ROTATION FAST - SLOW
190 - 193 NO ROTATION
194 - 255 CLOCKWISE ROTATION SLOW - FAST
Gobo’s
