Features & Functionality
2•1
FeatureS & Functionality
It is recommended that you first review the Pilot’s Handbook included with your device for
the basics on hardware controls, inputs & outputs. In this chapter, we’ll dive deeper into
the major features & functionality offered on POD® HD300 & POD® HD400.
Tuner Mode
The Tuner is available whenever the MODE footswitch is set to “Pedal On/Off” or “Presets”
Mode. To enter Tuner mode, press and hold the TA P button.* The volume is muted while
in Tuner mode, so you won’t hear any signal from your device.
* Note: Holding the TAP button when in “Looper” Mode triggers the “Clear Loop” function.
Please see “Using the Looper” on page 7•1 for more info.
Pluck an individual string on your guitar. When right-pointing arrows appear, your note is
flat; when left-pointing arrows appear, your note is sharp. The fewer the arrows, the closer
you are to the reference note. When two asterisks appear, your string is in tune.
Flat In Tune Sharp
Press the TAP switch, or any other footswitch, to exit Tuner Mode.
