Appendix B: MIDI
B•2
MIDI Dump - Backing Up Presets
To perform a MIDI Dump, connect POD HD to your computer’s USB port and prepare
your MIDI software to receive MIDI data from the device. Enter the Edit Mode on POD
HD, and navigate to the MIDI menu. Here you’ll see the following options:
• Current - Sends only data for the currently loaded Preset.
• All - Sends all data for all 128 Presets.
Select the preferred Dump option, press the TAP footswitch and the MIDI SysEx data will
immediately be fed to your computer. Once the dump has completed, name and save the
SysEx file. The SysEx file can be selected again any time in the future and sent to POD HD
to restore the Preset(s) on your device.
Restoring Presets
Once you have one or more POD HD SysEx dump files saved on your computer, open or
select the desired SysEx file and configure your MIDI software to send MIDI data to your
connected POD HD.
To restore a single Preset
If your selected SysEx file contains a single Preset (i.e. - you used the MIDI Dump “Current”
setting above to create the le):
• Call up the Preset location on your POD HD into which you want to import the
Preset.
• There is no special “receiving mode” setting on POD HD - it will always receive
MIDI.
• Initiate the transfer of the selected SysEx file from within your MIDI software.
• You should see and hear the new Preset loaded into the selected Preset location.
• Save the Preset - Your new, restored settings will not be retained in the device’s
Preset location unless you save the Preset.
