Working with Presets

3•1

Working With preSetS

POD® HD300 & POD® HD400 include the ability to store up to 128 Presets within

the device’s internal memory. These Presets are found within the 01A to 32D Bank and

Channel locations. In this chapter we’ll cover accessing and saving Presets. For details on

editing the many Tone parameters saved within Presets, please refer to “Edit Mode” on

page 4•1.

Accessing Presets

POD HD300/HD400 includes 32 Preset Banks (1 through 32), each containing 4 Channel

locations (A,B, C & D). Each location is capable of storing one Preset. There are two ways

to access the Presets on the device: using the Preset Select controls or using the Bank &

Channel footswitches.

Preset Select Controls

Use the 4-way Nav. Disc button, and PRESETS knob to navigate and load Presets.

Left/Right have no

function for the Preset

Select screen

Up/Down selects the

next/previous Bank

Currently loaded Preset

indicator LED

Rotate knob to select

and load the next/pre-

vious Preset

The amber LED indicator and the top row of the LCD screen shows the current Preset

location Bank/Channel. Use the Nav. Disc functions to increment through Presets one

Bank at a time.

The lower row on the screen displays the name of the current Preset - use the Presets knob

to scroll through Preset Channels incrementally.
