Features & Functionality
2•4
FX Loop (POD HD400 Only)
The FX Loop built into POD HD400 can be controlled with several options, including
“Pre” or “Post” positioning and level control. These options are accessed in the Edit Mode
- see “FX Loop Menu (POD HD400 Only)” on page 4•5.
Tap Tempo
Tap Tempo is the term we use to refer to the “system” tempo value that is
accessed via the TA P footswitch on your POD HD device. Stomp rhythmically
on the TAP footswitch to set your Tap Tempo. This Tempo is saved per Preset.
You’ll see the LED on the TA P switch blink to indicate your current Tap Tempo.
FX2 and FX3 model sets each offer a global Tap Control setting which congures these
effects’ modulation speed and delay time to sync to the Tap Tempo. See the “Common
Parameters” descriptions for FX2 on page 6•12 and FX3 on page 6•15 for details.
Pedal Control
The on-board Expression Pedal (and an additional Pedal 2 for POD HD400
devices) can be assigned to the Volume, Wah or FX1 Pitch Glide FX. For
most Presets, the pedal is pre-configured to control a Wah model for WAH
mode and the Volume model for the VOL mode. Clicking the Pedal’s “toe
switch” toggles between these two functions, and the device’s WAH or VOL
LED illuminates to indicate the current mode.
Pitch Glide
Either of these WAH or VOL modes can alternatively be assigned to control the Pitch
Glide model. This pedal assignment setting is found among the model’s Edit Mode
settings - see “Pitch Glide” on page 6•8. Pedal assignment for any of these 3 FX is saved
individually with each Preset. When controlling the Pitch Glide effect, you’ll see both the
WAH and VOL LEDs illuminated.
