Working with Presets
3•2
Bank & Channel Footswitches
Place the POD HD footswitches into Preset Mode for hands-free Preset selection by
pressing the MODE switch until the lower (green) LED is lit (also see “Footswitch Mode”
on page 1•3). This congures the 4 footswitches to the right to function as A, B, C & D
Channel switches.
The green LEDs indicate Preset Mode The lit A,B,C,D footswitch indicates
the selected Channel
Press the A, B, C or D switch to instantly recall its Channel location within the currently
selected Bank. For example, if the LED displays 12A, then Bank 12 is the current Bank,
and switches A, B, C and D will load Presets 12A, 12B, 12C and 12D, respectively. Bank
switching differs for POD HD300 and POD HD400 devices:
POD HD300 Bank Select: Press the A and B switches simultaneously for Bank Up, or
the B and C switches for Bank Down.
Press A+B for Bank Up Press B+C for Bank Down
POD HD400 Bank Select: Press for Bank Up, or for Bank Down.
Bank Down
Bank Up
