FX Models
6•12
Common FX2 Parameters
When you enter Edit Mode for any FX2 model, you’ll see the following common parameters
for most (as well as “Model Select” and “Routing,” as described on page 6•3):
Tap Control
Set this option to Control to have the Modulation speed of your FX2 models follow
whatever tempo you “tap” into your POD HD, using the TA P button. Set this parameter
to Don’t Ctl and the FX2 models’ Speed parameter can be adjusted to any speed you like,
regardless of the current Tap Tempo. The TapCtl setting is a “global” parameter. Also see
“Tap Tempo” on page 2•4.
Speed
Adjusts the modulation/oscillation/tremolo speed for the FX2 models.* The following
behaviors apply:
• If the TapCtl parameter (see previous item) is set to Don’tCtl, you can adjusts the
Modulation Speed manually, independent of the current Tap Tempo. This Speed
value is stored per Preset.
• If the TapCtl parameter is set to Control, the Modulation Speed follows the current
Tap Tempo. If you stomp out your desired 1/4 note rhythm on the TAP footswitch,
this will set a new Tap Tempo, and FX2 models will then follow this new tempo.
* Note that the FX2 Filter swoosh models offer slightly different Speed parameter options, as
detailed within the following model’s descriptions, as applicable.
