LINE 6 POD HD400 [26/83] Wah menu
![LINE 6 POD HD400 [26/83] Wah menu](/views2/2009074/page26/bg1a.png)
Edit Mode
4•4
Decay
Sets the Gate Decay. Higher levels result in a longer transition from non-gated to gated
audio.
WAH Menu
The WAH menu offers selection of any Wah model. This setting, as well as the Wah
enabled/disabled state and pedal assignment, are stored individually for each Preset.*
Please also see “Pedal Control” on page 2•4 and “Wah Models” on page 6•18.
*Note: Either the WAH and VOL pedal functions of POD HD can be alternatively assigned
to control the FX1 Pitch Glide effect per Preset for some wild pitch-bending antics. Please
see “Pitch Glide” on page 6•8.
VOL Menu
The VOL menu offers several options for how the POD HD pedal functions when set to
control the Volume effect. These parameters, as well as the pedal assignment (see “Pedal
Control” on page 2•4), are all stored individually for each Preset. The Volume effect is
enabled and disabled automatically via the status of your POD HD pedal (as indicated by
the WAH and VOL LEDs next to the pedal).
Routing
You’ll get slightly different sonic behaviors when positioning the Volume pedal before or
after the amp and some types of FX. Feel free to experiment here to get the desired results
for your Tone!
