Amp, Cab & Mic Models
5•5
Presence
Just as with the Presence knob found on the front panel of most tube amplifiers, this
brightens up your tone at higher settings.
Master Volume
NOTE: This Master Volume parameter, as well as the following Bias, and Bias Excursion
parameters, are functional only when using the “Full” Amp Model versions (see page 5•3).
The Sag and Hum parameters are functional for both “Full” and “Preamp” Amp Model versions.
We refer to these 5 controls as “Deep Edit Parameters” (or “DEPs”) for the Amp Models.
Use this Master Volume to adjust the amount of power amp distortion. This parameter is
highly interactive with all other Amp Model Deep Edit Parameters- the lower the Master
is set, the less effect the other controls will have.
Sag
Setting the Sag to minimum offers a “tighter” responsiveness, and turning clockwise
provides more “touch” dynamics & sustain.
Hum
Controls how much heater hum & AC ripple interacts with your tone. At the maximum
setting things get really freaky.
