USB Audio
8•4
Mac® - Line 6 Audio-MIDI Devices
Launch the Line 6 Audio-MIDI Devices utility from within the Mac®
System Preferences. This utility provides access to several driver options.
Line 6 Audio-MIDI Settings - Driver Options (Mac®)
There are two screens available within this window: Driver and Inputs & Recording.
3
2
1
4
5
7
6
Line 6 Audio-MIDI Settings window, Driver screen
1
Device Selector: Select your POD HD device here. If you have more than one
supported Line 6 audio device connected, each will be selectable in this list.
2
Driver Version: Displays the current device’s installed driver version number.
3
ESN: Displays the current device’s unique Electronic Serial Number.
4
Driver - Inputs & Recording Screen Selector: Use these buttons to display the
respective options for your device within this window.
