USB Audio
8•8
E
Volume sliders: These sliders offer level adjustment for the selected device.
• When viewing the Audio Device - Input screen (as shown above) the sliders control
the level of the Record Send signal fed to your recording software. These sliders can
be used to fine tune your DAW software’s recording level. Note that these sliders
offer a max level of +18dB, which can apply a boost to your input signal if needed.
• When viewing the Audio Device - Output screen (as shown in the following
screenshot) the sliders control the stereo level for your software’s audio playback fed
to POD HD. These sliders can be used to independently adjust the USB playback
audio versus your guitar input signal.
The Audio MIDI Setup utility, Output screen (Mac OS® X 10.6 and later*)
