AKG WMS40PRO SINGLE VOCAL [19/60] Setting up
![AKG WMS40PRO SINGLE VOCAL [19/60] Setting up](/views2/1000119/page19/bg13.png)
Note:
3.6 Setting Up the Handheld
Transmitter
Also refer to section 4 Microphone
Technique.
3.6.1 Replacing the Color Code Clip
Refer to fig. 9 on page 2.
3.7 Setting Up the Bodypack
Transmitter
Important!
3.7.1 Connecting a Microphone
Refer to fig. 10 on page 3.
Also refer to section 4 Microphone
Technique.
3.7.2 Connecting an Instrument
Refer to fig. 10 on page 3.
3.7.3 Inserting a Label
Refer to fig. 4 on page 2.
3.8 Before the Soundcheck
• If you use a rechargeable battery, the LED will switch to red 15 minutes before the battery will be dead!
5. To close the battery compartment, slide the battery compartment lid (14)/(21) onto the battery compartment from
below to the point that the snap hook will engage.
1. Switch power to the receiver on.
2. To switch power to the transmitter on, set the on/off switch (11) to "ON".
Since the HT 40 PRO handheld transmitter has been designed specifically for the integrated microphone element,
there is no need to set gain on the handheld transmitter. Therefore, the handheld transmitter has no level or gain
control.
3. Switch power to your sound system or amplifier on.
4. Talk or sing into the microphone and set the levels on your mixer or amplifier referring to the appropriate instruc-
tion manual, or by ear.
1. Pull the color code clip (13) off the transmitter case in the direction of the arrow.
2. Slide the supplied semitransparent replacement clip onto the transmitter to the point that it snaps into place with
an audible click.
The PT 40 PRO bodypack transmitter has been designed for use with the CK 55 L, C 417 L, C 520 L, C 555 L,
C 516 ML, C 518 ML, and C 519 ML microphones from AKG. If you wish to connect other microphones from AKG or
other manufacturers to the PT 40 PRO, please note that you may have to rewire the existing connector of your micro-
phone or replace it with a 3-pin mini XLR connector.
Audio input (18) pinout: Pin 1: shield
Pin 2: audio inphase (+)
Pin 3: supply voltage
A 4-V positive supply voltage for condenser microphones is available on pin 3.
Please note that AKG cannot guarantee that the PT 40 PRO bodypack transmitter will work perfectly with
products from other manufacturers and any damage that may result from such use is not covered by the AKG
warranty scheme.
1. Remove the battery compartment lid (21).
2. Plug the mini XLR connector on the cable of your microphone into the audio input socket (18) on the bodypack
transmitter.
3. Set the on/off switch (16) to "ON" to switch power to the bodypack transmitter on.
4. Switch power to the receiver on.
5. Talk or sing into the microphone.
6. Use the screwdriver (21a) integrated in the battery compartment lid (21) to set the GAIN control (22) to a position
where the AF CLIP LED (5) on the receiver will flash occasionally.
7. Replace the battery compartment lid (21) on the transmitter.
1. Remove the battery compartment lid (21).
2. Plug the jack plug on the MKG L guitar cable into the output jack on your instrument and the mini XLR connector
on the guitar cable into the audio input socket (18) on the bodypack transmitter.
3. Set the on/off switch (16) to "ON" to switch power to the bodypack transmitter on.
4. Switch power to the receiver on.
5. Play your instrument.
6. Use the screwdriver (21a) integrated in the battery compartment lid (21) to set the GAIN control (22) to a position
where the AF CLIP LED (5) on the receiver will flash occasionally.
7. Replace the battery compartment lid (21) on the transmitter.
1. Remove the battery compartment lid (21).
2. Remove a label from the supplied sheet.
3. Letter the label as desired.
4. Remove the battery and place the label on the viewing window (21b).
5. Replace the battery and slide the compartment lid (21) back in place on the transmitter.
1. Move the transmitter around the area where you will use the system to check the area for "dead spots", i.e., places
where the field strength seems to drop and reception deteriorates.
• If you find any dead spots, try to eliminate them by repositioning the receiver. If this does not help, avoid the dead
spots.
2. The RF OK LED (4) on the receiver going out means no signal is being received or the automatic squelch is active.
• Switch power to the transmitter ON or move closer to the receiver, to the point that the RF OK LED (4) will come back
on.
3 Setting Up
WMS 40 SINGLE/DUAL 19
L
!
WMS 40 SD_07_Hex 12/20/2007 11:26 Seite 19 (Schwarz/Black Auszug)
