7 Specifications
This product conforms to the standards listed in the Declaration of Conformity. To order a free copy of the Declaration of Conformity, visit http://www.akg.com or
contact sales@akg.com.
7.1 WMS 40 SINGLE/DUAL
Carrier frequency range
Modulation
Audio bandwidth
Frequency stability (-10°C to +50°C)
Rated deviation
T.H.D. at 1 kHz
Compander
Signal/noise ratio
RF output
Current consumption
Power requirement
Battery life
Audio input level for rated deviation
Input impedance
Condenser mic power supply
Squelch threshold
Audio outputs
Size
Net weight
HT 40 PRO
660 to 865 MHz
FM
65 HZ to 20 kHz
±15 kHz
15 kHz
typ. 0.8%
Yes
typ. 110 dB(A)
10 mW
typ. 70 mA
1 x 1.5 V AA size battery (LR 6 to IEC
86-L)
typ. 30 hours (for 2200 mAh)
-
-
-
-
-
229 x 53 x 53 mm
(9 x 2.1 x 2.1 in.)
160 g (5.7 oz.)
PT 40 PRO
660 to 865 MHz
FM
40 Hz to 20 kHz
±15 kHz
15 kHz
typ. 0.,8%
Yes
typ. 110 dB(A)
10 mW
typ. 75 mA
1 x 1.5 V AA size battery
(LR 6 to IEC 86-L)
typ. 30 hours (for 2200 mAh)
25 to 750 mV/1 kHz, adjustable
1 Mohm
4 V/4.7 kohms (pin 3)
-
-
60 x 74 x 30 mm
(2.4 x 2.9 x 1.2 in.)
60 g (2.1 oz.)
SR 40 SINGLE/DUAL
660 to 865 MHz
FM
40 Hz to 20 kHz
±15 kHz
15 kHz
typ. 0.8%
Yes
typ. 110 dB(A)
-
SR 40 SINGLE: typ. 95 mA
SR 40 DUAL: typ. 175 mA
120/230 VAC
50/60 Hz
-
-
-
-
-100 dBm
bal. 1/4" jack: adjustable
from mic to line level.
Output level at rated deviation:
500 mV rms
200 x 190 x 44 mm
(7.8 x 7.4 x 1.7 in.)
SR 40 SINGLE: 580 g (1.3 lbs.)
SR 40 DUAL: 620 g (1.4 lbs.)
22 WMS 40 SINGLE/DUAL
7.2 CK 55 L, C 555 L
Type
Polar pattern
Frequency range
Sensitivity
Electrical impedance at 1 kHz
Supply voltage
Cable length
Connector
Finish
Size
Net weight
CK 55 L
pre-polarized condenser microphone
cardioid
80 Hz to 14 kHz
19 mV/Pa (-34.4 dBV re 1 V/Pa)
1000 ohms
1.5 to 10 V from AKG WMS
bodypack transmitter
1.6 m (5 ft. 4 in.)
3-pin mini XLR
matte black
8 dia. x 22 mm (0.3 x 0.9 in.)
3 g (0.1 oz.) (w/o cable)
C 555 L
pre-polarized condenser microphone
cardioid
80 Hz to 20 kHz
35 mV/Pa (-29 dBV re 1 V/Pa)
200 ohms
B 29 L battery supply, MPA V L phnatom power
adapter, AKG WMS bodypack transmitter
1.5 m (5 ft.)
3-pin mini XLR
matte black
length: 195 mm (7.7 in.), max. dia.: 134 mm (5.3 in.)
26 g (0.9 oz.)
7.3 SO 40
Carrier frequency range 660 to 865 MHz
Modulation FM
Audio bandwidth 40 to 20,000 Hz
Frequency stability (-10°C to +50°C) ±15 kHz
Rated deviation 15 kHz (SP1, SP2: 13.5 kHz)
T.H.D. at 1 kHz typ. 0.8%
Compander integrated
Signal/noise ratio typ. 103 dB(A)
RF output typ. 5 mW
Current consumption typ. 75 mA
Power requirement single 1.5-V AAA size battery
Battery life >11 hours (dry battery)
>6 hours (rechargeable battery)
Audio input level for rated deviation 300 mV/1 kHz
Size (WxDxH) 22 x 30 x 98 mm (0.8 x 1.2 x 3.8 in.)
Net weight 36 g (1.3 oz.)
WMS 40 SD_07_Hex 12/20/2007 11:26 Seite 22 (Schwarz/Black Auszug)
