off and unplugged and that the saw blade has
stopped. Used saw blades may be hot.
Fitting and removing the saw blade (fi g. B and
C)
Warning! Before attempting any of the following
operations, make sure that the tool is switched
off and unplugged and that the saw blade has
stopped. Used saw blades may be hot.
Fitting the saw blade (fi g. B)
♦ Hold the saw blade (10) as shown, with the
teeth facing forward.
♦ Push and hold the blade clamp (11) down.
♦ Insert the shank of the saw blade into the
blade holder (12) as far as it will go.
♦ Release the blade clamp (11).
Saw blade storage (fi g. C)
Saw blades (10) can be stored in the storage
compartment (4) located on the side of the tool.
♦ Open the cover of the saw blade storage
compartment (4) by holding the tab on the top
of the cover and pulling it outward.
♦ The blades are retained in the compartment
by a magnetic strip. To remove a blade, press
down on one end of the blade to raise the
other end, and remove.
♦ Close the cover of the saw blade storage
compartment (4) and make sure that it is
latched closed.
Warning! Close the storage compartment door
securely before operating the saw.
Connecting a vacuum cleaner to the tool
(fi g. D)
An adaptor (13) is required to connect a vacuum
cleaner or dust extractor to the tool.
♦ Push the adaptor (13) into the dust extraction
outlet (6).
♦ Connect the vacuum cleaner hose (14) to the
adaptor (13).
Cut line blower (fi g. E)
♦ To aid visibility when cutting, your jigsaw is
equipped with a cut line blower (15) which will
keep the work area clear of dust as you saw.
Residual risks
Additional residual risks may arise when using the
tool which may not be included in the enclosed
safety warnings. These risks can arise from
misuse, prolonged use etc.
Even with the application of the relevant safety
regulations and the implementation of safety
devices, certain residual risks cannot be avoided.
These include:
♦ Injuries caused by touching any rotating/
moving parts.
♦ Injuries caused when changing any parts,
blades or accessories.
♦ Injuries caused by prolonged use of a tool.
When using any tool for prolonged periods
make sure you take regular breaks.
♦ Impairment of hearing.
♦ Health hazards caused by breathing dust
developer when using your tool (example:-
working with wood, especially oak, beech and
MDF).
Use
Adjusting the shoe plate for bevel cuts (fi g. F
and G)
Warning! Never use the tool when the shoe plate
is loose or removed.
The shoe plate (7) can be set to a left or right
bevel angle of up to 45°.
♦ Pull the shoe plate locking lever (5) outwards
to unlock the shoe plate (7) from the 0 deg
position.
♦ Pull the shoe plate (7) forward and set the
required bevel 15°, 30° and 45° indicated in
the bevel angle window.
♦ Push the shoe plate locking lever (5) back
towards the saw to lock the shoe plate (7).
To reset the shoe plate (7) for straight cuts:
♦ Pull the shoe plate locking lever (5) outwards
to unlock the shoe plate (7).
♦ Set the shoe plate (7) to an angle of 0° and
push the shoe plate backwards.
♦ Push the shoe plate locking lever (5) back
towards the saw to lock the shoe plate (7).
Setting the pendulum stroke (fi g. H)
♦ Set the pendulum stroke selector (9) to the
required position.
♦ Position 0: metal and aluminium and sheet
metal.
♦ Position I: for laminates, hard wood, work
tops.
♦ Position II: for plywood and PVC/Plastics.
♦ Position III: for soft wood and fast cutting.
Variable speed control
♦ Set the variable speed control knob (1) to the
required speed range.
♦ Use a high speed for wood, medium speed for
aluminium and PVC and low speed for metals
other than aluminium.
