VP-439 - Operating and Controlling the VP-439
11
11
LEVEL 1
LEVEL 2
LEVEL 3
SELECTION
Output
Resolution
Select the output resolution from the menu:
Resolution:
Appears as:
Resolution:
Appears as:
NATIVE
1600x900
1600x900
640x480
VGA
480i
480I
800x600
SVGA
480p
480P
1024x768
XGA
720p60
720P60
1280x1024
SXGA
1080i60
1080I60
1600x1200
UXGA
1080p60
1080P60
Resolution
continued
1366x768
WXGA
576i
576I
1680x1050
WSXGA
576p
576P
1920x1200
WUXGA
720p50
720P50
1280x800
1280x800
1080i50
1080I50
1440x900
1440x900
1080p50
1080P50
NATIVE - Select NATIVE to select the output resolution from the EDID
of the connected HDMI monitor
Audio
Output Volume
Set the output volume
Input Volume
Set the input volume
Delay
OFF/40ms/110ms/150ms/Auto
Input
Automatic/Analog/Embedded
OSD
H-Position
value
V-Position
value
Timer
Off/5/6/7…/100
Background
Set the transparency of the OSD (100 is fully
transparent)
Display
Info/On/Off
Advanced
HDCP On Input
On/Off (disabled for PC and CV)
Auto SYNC Off
Off/Fast/Slow
Auto Input Scan
Off/On/HDMI+PC/HDMI+CV/CV+PC
Auto Image
On/Off (disabled for HDMI and CV)
Freeze
Freeze+Mute/Mute Only/Freeze Only
Ethernet
IP Mode
DHCP/Static
Static IP
IP Address
xxx.xxx.xxx.xxx
Subnet Mask
xxx.xxx.xxx.xxx
Def. Gateway
xxx.xxx.xxx.xxx
UDP Port
50000
IP Address
xxx.xxx.xxx.xxx
MAC Address
xx:xx:xx:xx:xx:xx
Timing Shift
When ON (recommended), implements a small shift
on the horizontal sync which may resolve instabilities
seen on some displays working at specific
resolutions
