VP-439 - Operating and Controlling the VP-439
5.2.1 The OSD MENU
This table illustrates the MENU features and functions.
LEVEL 1
LEVEL 2
LEVEL 3
SELECTION
Contrast
value
Brightness
value
For the
PC input
Phase
value
Clock
value
H-Position
value
V-Position
Off/Low/Middle/High
FineTune
HDMI
HUE
Sets the color hue
SATURATION
Sets the color saturation
SHARPNESS
Sets the sharpness of the
NOISE
REDUCTION
Selects the noise reduction
level: OFF, HI, LOW and MID
(middle)
PC
PHASE
Sets the clock phase
CLOCK
Sets the clock frequency
H-POSITION
Sets the horizontal position of
the picture
V-POSITION
Sets the vertical position of the
CV
HUE
Sets the color hue
SATURATION
Sets the color saturation
SHARPNESS
Sets the sharpness of the
NOISE
REDUCTION
Selects the noise reduction
level: OFF, HI, LOW and MID
(middle)
H-POSITION
Sets the horizontal position of
the picture
V-POSITION
Sets the vertical position of the
Color
Red
value
Green
value
Blue
value
Input
Source
HDMI, PC/YPbPr, Video (CV)
Output
Size
Full / Over Scan / Under Scan / Letter Box /
Pan Scan /Best Fit
