![Kramer VP-439 [39/52] Kramer protocol 3000 command list](/views2/1153513/page39/bg27.png)
34
VP-439 - The RS-232/Ethernet (UDP) Communication Protocol
8.2 Kramer Protocol 3000 – Command List
Command
Short Form
Description
#
Protocol handshaking
#HELP
List of commands
#BUILD-DATE?
Read device build date
#FACTORY
Reset to factory default configuration
#MODEL?
Read device model
#PROT-VER?
Read device protocol version
#VERSION?
Read device firmware version
#NET-MAC?
NTMC?
Get MAC address
#NET-IP
NTIP
Set device IP address
#NET-IP?
NTIP?
Get device IP address
#NET-GATE
NTGT
Set Gateway IP
#NET-GATE?
NTGT?
Get Gateway IP
#NET-MASK
NTMSK
Set device subnet mask
#NET-MASK?
NTMSK?
Get device subnet mask
#NET-DHCP
NTDH
Set DHCP mode
#NET-DHCP?
NTDH?
Get DHCP mode
#ROUTE
Set input source
#ROUTE?
Get input source
#DISPLAY?
Get output HPD status
#HDCP-MOD
Set input HDCP
#HDCP-MOD?
Display input HDCP status
#VID-RES
Set input/output resolution
#VID-RES?
Get input/output resolution
#VFRZ
Set freeze
#VFRZ?
Display freeze status
#AUD-LVL
Set audio level
#AUD-LVL?
Get audio level
#MUTE
Set audio mute
#MUTE?
Display audio mute status
#SCLR-AS
Set auto sync mode
#SCLR-AS?
Display auto sync status
#IMAGE-PROP
Set size mode
#IMAGE-PROP?
Display size status
#SCLR-AUDIO-DELAY
Set audio delay mode
#SCLR-AUDIO-DELAY?
Display audio delay status
8.3 Kramer Protocol 3000 – Detailed Commands
This section describes the detailed commands list (see Section 8.3.3) as well as
the output resolutions key (see Section 8.3.1) and the input resolutions key (see
Section 8.3.2).
