VP-439 - Using the Embedded Web Pages

6 Using the Embedded Web Pages

The VP-439 can be operated remotely using the embedded Web pages. The Web

pages are accessed using a Web browser and an Ethernet connection.

Before attempting to connect:

 Perform the procedures in Section 5.4

 Ensure that your browser is supported

The following operating systems and Web browsers are supported:

Operating Systems

Applicable Browser Versions and Higher

Windows 7

Chrome: 25

Internet Explorer: 9

Firefox 19

Opera: 11

Mac (PC)

Chrome: 25

Firefox: 19

Opera: 11

iOS

Chrome: 25

Safari (depends on the IOS version)

Opera: 11

Android OS

Chrome: 25

Opera: 11

Note that some features might not be supported by some cellphone operating

systems.
