VP-439 - Technical Specifications
29
29
7 Technical Specifications
INPUTS:
1 HDMI with unbalanced stereo on a 3.5mm mini jack,
1 PC/HD (RGBHV/YPbPr) on a 15-pin HD connector with
unbalanced stereo on a 3.5mm mini jack,
1 composite video on an RCA connector with unbalanced
stereo on 2 RCA connectors
OUTPUTS:
1 HDMI on a DVI-I connector with unbalanced stereo on
2 RCA connectors
PORTS:
1 Ethernet on an RJ-45 connector, 1 RS-232 on a 9-pin
D-sub connector
OUTPUT COLORSPACE:
RGB/YPbPr
OUTPUT RESOLUTIONS:
1080i, 1080p, 576i, 576p, 720p, 1080i, 1080p, WXGA,
WSXGA, WUXGA, 1280x800, WXGA+, SXGA+,
NATIVE, VGA, SVGA, XGA, SXGA, UXGA, 480i, 480p,
1600x900
OUTPUT REFRESH RATE:
60Hz for computer graphics resolutions, 50/60Hz for
HDTV resolutions
PROCESSING DELAY:
30ms approx.
CONTROLS:
Front panel buttons, menu-driven OSD control, Web
page
POWER CONSUMPTION:
5V DC, 1.1A
OPERATING TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS:
21.5cm x 16.1cm x 4.36cm (8.46” x 6.34” x 1.7”) W, D, H
WEIGHT:
1.1kg (2.43lb) approx.
INCLUDED ACCESSORIES:
Power supply
OPTIONAL ACCESSORIES:
RK-1 19” rack adapter
Specifications are subject to change without notice at http://www.kramerelectronics.com
