Kramer VP-439 [41/52] The commands
![Kramer VP-439 [41/52] The commands](/views2/1153513/page41/bg29.png)
36
VP-439 - The RS-232/Ethernet (UDP) Communication Protocol
Resolution
CV
PC
HDMI
YPbPr
Key
480P
75
576P
77
720P@50Hz
78
720P@60Hz
79
1080I@50Hz
80
1080I@60Hz
81
1080P@24Hz
82
1080P@30Hz
87
1080P@50Hz
84
1080P@60Hz
85
8.3.3 The Commands
Command – HELP
Command Type – System-mandatory
Command Name
Permission
Transparency
Set:
-
-
-
Get:
HELP
End User
-
Description
Syntax
Set:
-
-
Get :
Get command list or help for specific
command
2 options:
1. #HELP␍
2. #HELP␠command_name␍
Command – BUILD-DATE
Command Type – System-mandatory
Command Name
Permission
Transparency
Set:
BUILD-DATE
End User
-
Get:
-
-
-
Description
Syntax
Set:
Read device build date
#BUILD-DATE?␍
Get :
-
-
Response
~nn@BUILD-DATE␠date␠ time␍␊
Parameters
date – Format: YYYY/MM/DD where YYYY = Year, MM = Month, DD = Day
time – Format: hh:mm:ss where hh = hours, mm = minutes, ss = seconds
