VP-439 - The RS-232/Ethernet (UDP) Communication Protocol
37
37
Command – FACTORY
Command Type – System-mandatory
Command Name
Permission
Transparency
Set:
FACTORY
End User
-
Get:
-
-
-
Description
Syntax
Set:
Reset device to factory defaults configuration
#FACTORY␍
Get :
-
-
Response
~nn@FACTORY␠OK␍␊
Notes
This command deletes all user data from the device. The deletion can take some time.
Command – MODEL?
Command Type – System-mandatory
Command Name
Permission
Transparency
Set:
-
-
-
Get:
MODEL?
End User
-
Description
Syntax
Set:
-
-
Get :
Get device model
#MODEL?␍
Response
~nn@MODEL␠model_name␍␊
Parameters
model_name – String of up to 19 printable ASCII chars
Command – PROT-VER?
Command Type – System-mandatory
Command Name
Permission
Transparency
Set:
-
-
-
Get:
PROT-VER?
End User
-
Description
Syntax
Set:
-
-
Get :
Get protocol version
#PROT-VER?␍
Response
~nn@PROT-VER␠ 3000:version␍␊
Parameters
Version – Format: XX.XX where X is a decimal digit
