![Kramer VP-439 [40/52] Output resolutions key](/views2/1153513/page40/bg28.png)
VP-439 - The RS-232/Ethernet (UDP) Communication Protocol
35
35
8.3.1 Output Resolutions Key
Resolution
Key
Resolution
Key
Resolution
Key
640x480
200
1440x900
208
1080i60
216
800x600
201
1400x1050
209
1080p60
217
1024x768
202
1680x1050
210
576p
218
1280x768
203
1600x1200
211
720p50
219
1360x768
204
1920x1080
212
1080i50
220
1280x720
205
1920x1200
213
1080p50
221
1280x800
206
480p
214
Native
222
1280x1024
207
720p60
215
8.3.2 Input Resolutions Key
Resolution
CV
PC
HDMI
YPbPr
Key
NTSC
0
PAL
1
640x480 @60Hz (VGA)
6
640x480 @72Hz (VGA)
8
640x480 @75Hz (VGA)
9
800x600 @56Hz (SVGA)
11
800x600 @60Hz (SVGA)
12
800x600 @72Hz (SVGA)
14
800x600 @75Hz (SVGA)
15
1024x768 @60Hz (XGA)
20
1024x768 @70Hz (XGA)
21
1024*768 @75Hz (XGA)
23
1152x864 @75Hz (XGA+)
27
1280x720 @60Hz
30
1280x768 @60Hz
33
1280x960 @60Hz
36
1280x1024 @60Hz
40
1280x1024 @75Hz
41
1360x768 @60Hz
43
1400x1050 @60Hz (SXGA+)
48
1440x900 @60Hz (WXGA+)
51
1600x1200 @60Hz (UXGA)
56
1680x1050 RB @60Hz (WSXGA)
61
1920x1080 @60Hz
65
1920x1200 RB @60Hz
66
1280x800 @60Hz
70
480I
74
576I
76
