Kramer VP-439 [35/52] Default communication parameters

VP-439 - Technical Specifications

7.1 Default Communication Parameters

RS-232

Baud Rate:

9,600

Data Bits:

Stop Bits:

Parity:

None

Ethernet

To reset the IP settings to the factory reset values go to : Menu-> Factory-> RESET->Change

the option to YES and press Enter

IP Address:

192.168.1.39

Subnet mask:

255.255.255.0

Default gateway:

192.168.0.254

Default UDP Port #:

50000

Maximum UDP Ports:

Full Factory Reset

OSD

Go to : Menu-> Factory-> RESET->Change the option to YES and

press Enter

RS-232/Ethernet (UDP) Command Protocol

Command Format:

ASCII protocol 3000

Example (Route the video input to the output):

#ROUTE 12,1,2<cr>
