VP-439 - Using the Embedded Web Pages

6.6 The EDID Management Page

The EDID page lets you copy a selected resolution from the DVI output or the

default resolution (Default HDMI or Default VGA) to one or both inputs (HDMI and

PC).

Figure 16: The EDID Page

Figure 17 shows how to select a resolution (the DVI output in this example) and

select one or both inputs. To copy, click the Copy button:
