169
6. Installation and Connections
1. Pressthe buttontosettheprojectortothestandbymode,then
turnoffthemainpowerswitch.
2. Removetheplate(portcover).
Loosenthescrewsecurityportcover.
• Thescrewisnotremovable.
3. Slowly insert the wireless LAN unit into the USB (LAN) port
( ).
- RemovethewirelessLANunit’scap,settheunitwiththefront(the
sidewiththeindicator) facing upwards,hold thebackedge and
inserttheunitgently.
Next,pressthewirelessLANunitinwithanger.
- ThecapyouhaveremovedwillbeusedwhenthewirelessLANunit
isremoved,sostoreitinasafeplace.
NOTE:IfthewirelessLANunitishardtoinsert,donotpushitinbyforce.
4. Attachtheanti-theftcapforwirelessLANunit.
UsethescrewyouremovedatStep2tosecuretheanti-theftcap.
Plate
Anti-theft cap
