33
2. Projecting an Image (Basic Operation)
Carrying the Projector
Preparation:Makesurethattheprojectoristurnedoff.
1. Unplugthepowercord.
2. Disconnectanyothercables.
• RemovetheUSBmemoryifitisinsertedintotheprojector.
• Removethelensbeforeshippingtheprojector.
3. Mountthelenscaponthelens.
4. Beforemovingtheprojector,screwinthetiltfeetiftheyhavebeenlengthened.
NOTE:
• Donotapplystrongshockorforcetotheprojectorwhilecarryingtheprojector.
• Removethelensbeforemovingtheprojector.Attachthelenscaptothelensandthedustcaptothelenshoodoftheprojector.
• Usetheoriginalcartonwhenshippingtheprojectorwithoutthelens.Improperpackagingmaycausedamagetotheprojector
during shipping.
