8. User Supportware
4 Check( )theprojectortoconnectandclick[Connect].
Ifthenameoftheprojectortoconnectisnotonthelistorifitishidden,click[Update].
4-1
4-2
Click
Click
Thescreenofyourcomputerwillbeprojectedfromtheprojector.
Atthistime,theinputsignaloftheprojectorwillautomaticallychangeto“NETWORK”.
NOTE:
• Whentheprojectorisfound,“1280×800”willbedisplayedintheresolutioneld.
•Transferringimages
Whenyourcomputerisconnectedtotheprojector,thescreenofthecomputerisprojectedfromtheprojectorasis.To
makeyourpresentationbyusingaPowerPointle,openthePowerPointleandstartyourpresentation.
