76
4. Using the Viewer
•Indexle(extension:.idx)
• Index les, which is converted by usingViewer PPT
Converter3.0,willappearintheThumbnailscreen.
Only folders and JPEG files converted by using
ViewerPPTConverter3.0willappearintheThumbnail
screen.
• Toselectslideshowofindexles,openthe[PRESENTA-
TION]folderintheDRIVELISTscreen.
However,indexleswillnotappear. Only folders and
JPEGleswillappear.
• UptofourindexfoldersinyourUSBandsharedfolder
aredisplayed.Thefourfolderswillbedisplayedinreverse
chronological order
• WhenyouinserttheUSBmemorydevicestoringindex
withtheViewerinoperation,thecontentoftheindexles
willbedisplayed.
NOTE:
• Theplaymode(MANUAL/AUTO)forslidesofindexleworksin
the following way:
Incaseof[MANUAL]for[PLAYMODE]
Whenyouselect[OPTIONS]→[SLIDESETTING]→[PLAYMODE]
→[MANUAL],indexleswillbesetformanualplaybackinregard-
lessofwhether[INTERVAL]isset.
Incaseof[AUTO]selectedfor[PLAYMODE]
Whenyouselect[OPTIONS]→[SLIDESETTING]→[PLAYMODE]
→ [AUTO],indexleswill be set for auto playback at intervals
speciedbyusing[INTERVAL].
When,however,[-1]isselectedfor[INTERVAL],theplaymodewill
besetforautoplaybackaccordingtothesettingfor[OPTIONS]→
[SLIDESETTING]→[INTERVAL].
7. RemovetheUSBmemoryfromtheprojector.
Returntothedrivelistscreen.MakesurethattheLEDon
theUSBmemoryisnotashingbeforeremovingtheUSB
memory.
NOTE:IfyouremovetheUSBmemoryfromtheprojectorwithaslide
displayed, the projector may not operate correctly. If this happens,
turn off the projector, turn off the main power switch, and unplug the
powercord.Wait3minutes,thenconnectthepowercord,turnon
the main power switch, and turn on the projector.
Exiting the Viewer
1. PresstheSOURCEbuttontoselectasourceotherthan
[VIEWER].
ApressoftheSOURCEbuttonwilldisplaythesourceselect
screen.
A few more presses of the SOURCE button will display
another source.
• To exit theViewer using the remote control, select a
sourceotherthan[VIEWER].
